Franke T 200 - 1 General Description of the Machine

3
11-03-2014 / LSC 044 / Rev. 00
1 GENERAL DESCRIPTION OF THE MACHINE
LEGEND
1. Top cup grid
2. Steam tap
3. Touchpad
4. Hot water tap
5. 2-cup filter holder
6. Steam wand
7. Drip tray grid
8. Water drip tray
9. Main on/off switch
10. Adjustable foot
11. Opening for gas burner inspection
12. Gauge
13. 1-cup filter holder
14. Hot water spout
15. Control knob for gas delivery (optional)
16. Piezoelectric lighter for gas (optional)
17. Electric cup warmer button (optional)
Fig. 1
43
1 2
2
3
6
15
16
13
14
10
17
9
8
7
6
5
1211
