Step 5: Electrical Conduits
Install pull box after aPower cable hole
1. Select appropriate pull box according to the cable
distribution direction. Max. size: 4.8inx2.75inx2.2in
(L*W*H)
2. Use a #3X4” Phillips head cross screwdriver to take the
junction box apart.
3. Use a wrench to install the pull box behind the user
port compartment.
Diameter: 35mm
Diameter: 22.5mm
4. Use a diagonal cutting plier to remove the
knockout holes on the side gratings.
5. Install the three side trim gratings.
38
