FRANKLINWH aPbox - Product Overview; RC65 Model; RC65 Specifications

aPbox Manual
6
Product Overview
Both models of aPbox, RC65 and RM65, can be used to
measure the amount of electricity generated by a PV
system, in addition to which RC65 can also be used as a
disconnect to sever the connection to the PV system.
Both the RC65 and RM65 support access of up to two PV
systems with a total current of no more than 65A.
RC65
Specifications
Electrical Specifications
Nominal Voltage
120/240VAC, split
Frequency
60 Hz
Rated Output Current
1 circuit, max 65A
Rated Input Current
2 circuits, max 65A total
Mechanical Specifications
Dimensions (W x H x D)
11.8 in. x 17.7 in. x 5.9 in.
(300mm x 450mm x 150mm)
Weight
21.2 lbs. (9.6kg)
Mounting Options
Wall mount (Indoors/Outdoors)
Environmental Specifications
Operating Temperature Range
-4°F ~122°F (-20°C ~50°C)
Storage Temperature Range
-22°F ~140°F (-30°C ~60°C)
Operating Humidity (RH)
0~100%
Maximum Altitude
9843 feet (3000 meters)
Type of Enclosure
NEMA 3R
Compliance Information
Compliance
FCC
