Install Sensors
The information available on the J1939 databus varies depending on the particular
engine type. The sensors (if any) that need to be installed will also vary depending on
the engine.
The sensors are wired to the optional 6-pin connector at the rear of the control
module. Refer to the Wiring Section for connector pinout and wiring information.
Install Buzzer
Install the buzzer close to the control module so the audible warning is easily
associated with the visual warning on the display.
The optional buzzer provided by FRC requires a cutout hole of 1-1/8" (1.125").
Pin 7 on the 8-pin connector at the rear of the control module is used to connect
the buzzer. Connect the ground side of the buzzer to pin 7. (Maximum current through
pin 7 is 300 mA.) Refer to the Wiring section (Figure 5).
Install High-Idle Kit
The high-idle is activated when +12 VDC is provided to pin 4 (High-Idle Active
Input) of the 8-pin connector and to pin 3 (Interlock Input) of the 12-pin connector.
Refer to High-Idle Wiring.
Note: It is important that the connection to the Interlock Input from the
High-Idle circuit be isolated from the apparatus interlock wiring with the
two diodes. The pump must NOT be engaged when using the high-idle
function and the THROTTLE READY LED will be off.
Install Remote Governor Option
Refer to Install Control Module for dimensions. The remote governor is connected
to power, the J1939 CAN Bus, and the FRC datalink. Refer to Wiring Section.
Note: Program code P303 SYS TYPE must be set to REMOTE in the
remote governor program.
