Specications
The governor is available in various models. Each model is programmed to interface
with specic engines. All models provide the same functions, controls, and digital
readouts for the management of pump discharge pressure.
Control Module
Supply Power: 12/24 VDC
Supply Current: 1.8 Amp
Dimensions: 10 1/2" Wide by 5 1/2" High
Unit of Measure: PSI °F (Program Option for kPa, Bar, °C)
LED Bar Graphs
Engine Oil Pressure: 10 - 100 PSI
Engine Coolant Temperature: 150 - 240 °F
Transmission Temperature: 140 - 300 °F
Battery Voltage: 11.5 to 15.5 VDC (12 V)
23.0 - 30 VDC (24 V)
Pressure Sensor
Discharge Intake
Model Number: XE-FP4000PT3 XE-IO3100PT3
Pressure Range: 0 - 600 PSI -30 in/Hg - 600 PSI
Proof Pressure: 1200 PSI 1200 PSI
Excitation Voltage: 5 VDC 5 VDC
Output Voltage: 0.5 - 4.75 VDC (See Table 1)
Table 1. Pressure Sensor Output Voltage
0psi 100psi 150psi 200psi 250psi 300psi 600psi
Discharge Sensor
XE-FP4000PT3
0.5vdc 1.21vdc 1.56vdc 1.92vdc 2.27vdc 2.625vdc 4.75vdc
Intake Sensor
XE-IO3100PT3
0.604vdc 1.295vdc 1.640vdc 1.985vd 2.331vdc 2.667vdc 4.75vdc
