Tilt Mechanism—Foot Activated Tilt (cont.)
POS. ITEM # DESCRIPTION QTY ASSY NOTES:
1 18088-2 FOOT ACTIV TILT ASSY COMP NXT 1 1 INCLUDES POS. 3, 6-24
2 18099-1 FOOT ACTIV TILT PEDAL ASSY 1 1 INCLUDES POS. 10-11, 16, 18, 21, 24
3a 18091-L TILT MECH LOCK ONLY - NXT L 1 1
3b 18091-R TILT MECH LOCK ONLY - NXT R 1 1
3 18091-2 TILT MECH LOCK ONLY - NXT PR 2 1
4a 18092-L MECH LOCK MTG BRKT LWR NXT L 1 1 ALL FRAMES
4b 18092-R MECH LOCK MTG BRKT LWR NXT R 1 1 ALL FRAMES
4 18092-2 MECH LOCK MTG BRKT LWR NXT 2 1 ALL FRAMES
5a 18150-L MECH LOCK MTG BRKT UPR NXT L 1 1 TALL TILT FRAMES ONLY
5b 18150-R MECH LOCK MTG BRKT UPR NXT R 1 1 TALL TILT FRAMES ONLY
5 18150-2 MECH LOCK MTG BRKT UPR NXT 1 1 TALL TILT FRAMES ONLY
6 18094-1 FOOT ACT TILT PEDAL CABLE 15" 1 1 ALL FRAMES - PEDAL TO JUNCTION BLOCK
7a 18151-1 FT ACTIV TILT MECH CABLE 10" 1 1 SMALL FRAME ONLY JUNCTION TO MECH RIGHT
SIDE
7b 18152-1 FT ACTIV TILT MECH CABLE 15" 1 1 MED & LONG FRAME JUNCTION TO MECH RIGHT
SIDE
8a 18153-1 FT ACTIV TILT MECH CABLE 20" 1 1 10-12 WIDE FRAME JUNCTION TO MECH LEFT
SIDE
8b 18154-1 FT ACTIV TILT MECH CABLE 25" 1 1 13-16 WIDE FRAME JUNCTION TO MECH LEFT
SIDE
8c 18155-1 FT ACTIV TILT MECH CABLE 30" 1 1 17-20 WIDE FRAME JUNCTION TO MECH LEFT
SIDE
9 18095-1 TILT CABLE JUNCTION BLK NXT 1 1 FOR FOOT & SINGLE HAND ACTIVATIONS
10 18096-1 FOOT TILT PEDAL BODY NXT 1 1
11 18097-1 NXT TILT RELEASE PEDAL ONLY 1 1
12 18098-1 TILT CABLE ADJ END FITTING 1 1
13 9125-4 NUT 10MM JAM NUT 4 1
14 8997-4 RUBBER BUSHING - THIN 4 2
15 9034-4 SCREW 1/4-20 X 1-1/4" BHCS 4 1
16 9035-4 SCREW 1/4-20X 1-1/2" BUTTON 4 1
17 9036-4 SCREW 1/4-20 X 1-3/4" BUTTON 4 1
18 8713-2 SCREW 5/16-18 x 1-1/2" BUTTON 2 1
19 9083-1 SCREW 5/16-18 X 2-3/4" HEX HD 1 1
20 9072-4 LOCKNUT 1/4-20 NYLON 4 1
21 9073-4 LOCKNUT 1/4-20 NYLON-THIN 4 1
22 9088-4 LOCKNUT 5/16-18 NYLOC-THIN 4 1
23 9074-4 WASHER 1/4" FLAT 1/2" OD 4 1
24 9089-4 WASHER 5/16" FLAT 4 1
To Next Page
