Freedom NXT - NXT Backpost Depth Setting Matrix

64
FREEDOM DESIGNS, INC.
WPCNXT 62013
M Tilt Mech Lock Location
P
Pivot Location
B
Backpost Bracket Location
14" ‡ STD / SRO / *** M P B B
15" ‡ STD / SRO / *** M P B B
16" STD / SRO / LEAF M P B B
17" STD / SRO / LEAF M P B B
18" STD / SRO / LEAF M P B B
* DIMENSIONS COULD VARY AS MUCH AS +/- 1/2”
‡ REQUIRES MECH LOCK SPLIT COLLARS & CHANGES SEAT RAIL TO +5°,
TRANSPORT BRACKETS MUST BE INVERTED TO CLEAR HANGER LATCH.
*** LEAF NOT POSSIBLE: POS. 1 & 2 NEEDED FOR SEATING HARDWARE
CLEARANCE.
SHORT FRAME
MEDIUM FRAME
LONG FRAME
12" ‡ STD / SRO / *** M P B B
13" ‡ STD / SRO / *** M P B B
14" STD / SRO / LEAF M P B B
15" STD / SRO / LEAF M P B B
16" STD / SRO / LEAF M P B B
16" STD / SRO / LEAF M P B B
17" STD / SRO / LEAF M P B B
18" STD / SRO / LEAF M P B B
19" STD / SRO / LEAF M P B B
20" STD / SRO / LEAF M P B B
21" STD / SRO / LEAF M P B B
22" STD / SRO / LEAF M P B B
B A C K P O S T D E P T H S E T T I N G ( I N C H E S ) *
14” 15” 16” 17” 18”
B A C K P O S T D E P T H S E T T I N G ( I N C H E S ) *
16” 17” 18” 19” 20” 21” 22”
B A C K P O S T D E P T H S E T T I N G ( I N C H E S ) *
12” 13” 14” 15” 16”
FRAME HOLE POSITION (POS.) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
FRAME HOLE POSITION (POS.) 1 2 3 4 5 6 7 8 9 10 11 12 13 14
FRAME HOLE POSITION (POS.) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
19
NXT Backpost Depth Setting Matrix
ThismatrixdetailstheTiltMechLock(M),TiltPivot(P),and
BackpostBracket(B)locationsontheseatrailforeachcongured
Backpostdepthsetting.
