Freedom NXT - High Mount Bracket

58
FREEDOM DESIGNS, INC.
WPCNXT 62013
Footrests—High Mount Bracket (cont.)
POS. ITEM # DESCRIPTION QTY ASSY NOTES:
1 18135-1 HIGH MOUNT - TUBE & CLAMP STYL 1 1
ALL 75 DEGREE HANGERS AND 90 DEGREE LATCH
1 18135-2 HIGH MOUNT - TUBE & CLAMP STYL 2 1
ALL 75 DEGREE HANGERS AND 90 DEGREE LATCH
2 18136-L HIGH MOUNT BRKT 90 POP-UP L 1 1 90 DEGREE POP-UP ONLY
2 18136-R HIGH MOUNT BRKT 90 POP-UP R 1 1 90 DEGREE POP-UP ONLY
2 18136-2 HIGH MOUNT BRKT 90 POP-UP PR 2 1 90 DEGREE POP-UP ONLY
3 18137-1 HIGH MOUNT BRACKET BASE 1 1
4 18138-1 HIGH MOUNT BRKT SWIVEL BAR 1 1
5 9033-4 SCREW 1/4-20 X 1" BUTTON HEAD 4 1
6 9035-4 SCREW 1/4-20X 1-1/2" BUTTON 4 1
7 9073-4 LOCKNUT 1/4-20 NYLON-THIN 4 1
8 9074-4 WASHER 1/4" FLAT 1/2" OD 4 2
9 20100-1 SPACER SLEEVE TEL FTRST EXT 1 1
10 20101-1 4" TEL FTRST EXT TUBE ONLY 1 1
11 18139-1 HIGH MOUNT TUBE ONLY 1 1
11 18139-2 HIGH MOUNT TUBE ONLY 2 1
12 3024 FRAME CLAMP - ANG ADJ REM FTBD 2 2 INCLUDES INNER AND OUTER CLAMP
13 9023-4 SCREW 1/4-20 X 2” HEX HEAD 4 2
14 9000-4 1” TUBE PLUG 4 2
15 9072-4 LOCKNUT 1/4-20 NYLON 4 2 NOT SHOWN
