Freedom NXT User Manual

142
FREEDOM DESIGNS, INC.
WPCNXT 62013
Appendix—Technical Specications (cont.)
NXT Wheel / Caster Seat to Floor Heights
Wheel Caster Pivot Height Wheel Caster Pivot Height
12" 3" Short 12.5" 18" 5" Tall 16.5"
12" 3" Tall 14" 18" 5" Short 15.5"
12" 3" Short 13" 18" 5" Tall 17"
12" 3" Tall 14.5" 18" 6" Short 15.5"
12" 4" Short 13.5" 18" 6" Tall 17"
12" 4" Tall 15" 20" 4" Short 14"
12" 5" Short 15.5" 20" 4" Tall 15.5"
12" 5" Tall 17" 20" 4" Short 14.5"
12" 6" Short 16" 20" 4" Tall 16"
12" 6" Tall 17.5" 20" 4" Short 15"
16" 3" Short 12.5" 20" 4" Tall 16.5"
16" 3" Tall 14" 20" 5" Short 14.5"
16" 3" Short 13" 20" 5" Tall 16"
16" 3" Tall 14.5" 20" 5" Short 15"
16" 4" Short 13.5" 20" 5" Tall 16.5"
16" 4" Tall 15" 20" 5" Short 15.5"
16" 4" Short 14" 20" 5" Tall 17"
16" 4" Tall 15.5" 20" 6" Short 15.5"
16" 4" Short 14.5" 20" 6" Tall 17"
16" 4" Tall 16" 20" 6" Short 16"
16" 5" Short 14.5" 20" 6" Tall 17.5"
16" 5" Tall 16" 20" 7" Short 16.5"
16" 7" Short 16.5" 20" 7" Tall 18"
16" 7" Tall 18"
18" 3" Short 12.5" 22" 4" Tall 16.5"
18" 3" Tall 14"
18" 3" Short 13" 22" 5" Tall 16.5"
18" 3" Tall 14.5"
18" 4" Short 13.5" 22" 5" Tall 17"
18" 4" Tall 15"
18" 4" Short 14" 22" 6" Tall 17"
18" 4" Tall 15.5"
18" 4" Short 14.5" 22" 6" Tall 17.5"
18" 4" Tall 16"
18" 4" Short 15" 22" 7" Tall 18"
18" 4" Tall 16.5"
18" 5" Short 14.5" 24" 6" Tall 17.5"
18" 5" Tall 16"
18" 5" Short 15" 24" 7" Tall 18"
Note: All 22” and 24” wheels not with short tilt pivot.
Note: All measurements may vary +/- 3/8"
Note: Measurements may vary +/- 1/2" when choosing foot or hand activated
wheel locks
