110
FREEDOM DESIGNS, INC.
WPCNXT 62013
Wheel locks—Hand Activated Drum Brake (cont.)
POS. ITEM # DESCRIPTION QTY ASSY NOTES:
1 18505-2 HAND ACTIV DRUM BRAKE-W/L NXT 1 1 ALL WHEEL SIZES BEFORE 2/28/2013 / EFFECTIVE
3/1/2013 ALL BUT 16 & 18 WHEELS
1 18506-2 HND ACTV DRM BRK W/L NXT 16/18 1 1 DRUM WHEEL LOCK 16 & 18” WHEELS ONLY
(EFFECTIVE 3/1/2013)
2* 18525-1 HAND ACTIV BRAKE-W/L HNDL ASSY 1 2 HANDLE & CABLE MUST BE REPLACED AS A UNIT
2* 18525-2 HAND ACTIV BRAKE-W/L HNDL ASSY 2 1 HANDLE & CABLE MUST BE REPLACED AS A UNIT
3 18526-1 COMBO TILT GREEN TRIGGER/CBL 1 1 NEEDED FOR COMBO TILT / HAND ACTIVATED
WHEEL LOCKS. NOT INCLUDED WITH #2
4 18527-1 AXLE Q/R 4-5/8 X 1/2" DRUM LOC 1 1 FOR ALL WHEELS EFFECTIVE 3/1/2013
4 18527-2 AXLE Q/R 4-5/8 X 1/2" DRUM LOC 2 1 FOR ALL WHEELS EFFECTIVE 3/1/2013
5 18528-1 AXLE Q/R 5" X 1/2" DRUM LOC 1 1 DRUM BRAKE FOR 16 & 18" WHEELS ONLY UNTIL
2/28/2013
5 18528-2 AXLE Q/R 5" X 1/2" DRUM LOC 2 1 DRUM BRAKE FOR 16 & 18" WHEELS ONLY UNTIL
2/28/2013
6a 18530-L DRUM BRAKE & LOCK MECHANISM L 1 1
6b 18530-R DRUM BRAKE & LOCK MECHANISM R 1 1
6 18530-2 DRUM BRAKE & LOCK MECHANISM PR 1 1
7 18531-L DRUM BRAKE MECH MNTNG PLATE L 1 1
7 18531-R DRUM BRAKE MECH MNTNG PLATE R 1 1
8 18532-1 DRUM BRAKE AXLE PLATE 1 1
9a 18533-1 DRUM BRAKE AXLE SLEEVE 2-3/4" 1 1
9b 18534-1 DRUM BRAKE AXLE SLEEVE 2-1/4" 1 1 16 & 18" WHEELS ONLY / EFFECTIVE 3/1/2013
10 18535-1 AXLE SLEEVE SPACER 5/16 X 3/4" 1 1
11 9121-4 NUT 3/4-16 JAM NUT ZINC 4 1
12 18536-2 DRUM BRAKE - W/L SHOE SET 1 1 ONE SET DOES ONE WHEEL
13 18537-1 DRUM BRAKE SHOE RETURN SPRING 1 1
14 18538-1 DRUM BRAKE SHOE BACKING SPACER 1 1
15 18539-1 DRUM BRAKE SHOE CAM 1 1
16 18540-1 DRUM BRAKE SHOE CAM ARM 1 1
17 9122-4 SCREW 5MM X 8MM BHCS 4 1
18 18542-1 BRAKE SHOE RETAINER CLIP 1 1
19 18543-1 CABLE ANCHOR BOLT 1 1
20 9123-4 WASHER 6MM ID CHROME FLAT 4 2
21 9124-4 NUT 10MM CHROME LOCK NUT 4 1
22 18544-1 CABLE END ADJ FITTING - DRUM BRAKE 1 1 10MM WRENCH FOR ADJUSTMENT
23 9125-4 NUT 10MM JAM NUT ZINC 4 1
24 18002-1 NXT AXLE PLATE MTG BRKT 1 1
25 18003-1 NXT AXLE PLATE MTG BRKT CLMP 1 1
26 9037-4 SCREW 1/4-20 X 2" BUTTON HD 4 2
27 9128-4 SCREW 1/4-20 X 2-1/4" BHCS 4 1
28 9129 SCREW 1/4-20 X 7/8” FLAT HEAD
29 9062-4 SCREW 1/4-20X1 1/4" SCKET HEAD 4 2
30 9073-4 LOCKNUT 1/4-20 NYLON-THIN 4 3
31 9074-4 WASHER 1/4" FLAT 1/2" OD 4 6
