Freedom NXT - Adjustable Height, Tall

FREEDOM DESIGNS, INC.
13
WPCNXT 62013
Armrest—Adjustable Height, Tall
STANDARD SEAT WIDTH REQUIRES (1) INNER CLAMP (ITEM 5)
AND USES 1-1/4” LONG MOUNTING SCREW (ITEM 20a)
EXTENDED SEAT WIDTH REQUIRES (2) INNER CLAMPS AS
SHOWN AND USES 1-1/2” LONG MOUNTING SCREWS (ITEM 20b)
1
2
3
18
14
13 12
10
22
11
7
5
6
21a/b 23
22 16 22 8
1920159
(See notes)
4
17
6
24
24
25
See Appendix for seat rail
to arm pad height ranges.
