12
FREEDOM DESIGNS, INC.
WPCNXT 62013
Armrests—Flip Back, Telescoping-Locking (cont.)
POS. ITEM # DESCRIPTION QTY ASSY NOTES:
1a 18140-L LKG F/BK TEL ARM 10.5-13.5 D L 1 1 INCLUDES POS. 2, 3a, 4-5a, 6-17 (no pad included)
1a 18140-R LKG F/BK TEL ARM 10.5-13.5 D R 1 1 INCLUDES POS. 2, 3a, 4-5b, 6-17 (no pad included)
1a 18140-2 LK F/BK TEL ARM 10.5-13.5 D PR 2 1
INCLUDES 2 EACH POS. 2, 3a, 4-17 (no pad
included)
1b 18143-L LKG F/BK TEL ARM 10.5-13.5 F L 1 1 INCLUDES POS. 2, 3b, 4-5a, 6-17 (no pad included)
1b 18143-R LKG F/BK TEL ARM 10.5-13.5 F R 1 1 INCLUDES POS. 2, 3b, 4-5b, 6-17 (no pad included)
1b 18143-2 LK F/BK TEL ARM 10.5-13.5 F PR 2 1
INCLUDES 2 EACH POS. 2, 3b, 4-17 (no pad
included)
1c 18147-L LKG F/BK TELE ARM 17-20" L 1 1 INCLUDES POS. 2, 3c, 4-5a, 6-17 (no pad included)
1c 18147-R LKG F/BK TELE ARM 17-20" R 1 1 INCLUDES POS. 2, 3c, 4-5b, 6-17 (no pad included)
1c 18147-2 LKG F/BK TELE ARM 17-20" PR 2 1
INCLUDES 2 EACH POS. 2, 3c, 4-17 (no pad
included)
2 18141-1 LCKNG TLSCPNG ARM REAR ASSY 1 1
3a 18142-1 ADJUST LCKG ARMRST TUBE DESK 1 1 NEEDED FOR DESK PADS 7.25" LONG
3b 18145-1 ADJUST LCKG ARMRST TUBE FULL 1 1 NEEDED FOR FULL LENGTH PADS 11" LONG
3c 18146-1 ADJUST LCKG ARMRST TUBE 17-20 1 1 NEEDED FOR 17-20 L FULL PADS ONLY 14" LONG
4 6014 F/BCK ARMREST MTG PLATE 1 1
5a 6004-L LKG F/BCK ARM ADJ PLATE - L 1 1
5b 6004-R LKG F/BCK ARM ADJ PLATE - R 1 1
5c 6004-2 LKG F/BCK ARM ADJ PLATE - PR 2 1
6 9000-4 TUBE PLUG - 1" 4 1
7 9005-2 PLSTIC SDL 1" FOR 5/16" SCREW 2 1
8 9022-4 SCREW-1/4-20 X 1 3/4" HEX HEAD 4 2
9 9023-4 SCREW 1/4-20 X 2" HEX HEAD 4 1
10 9104-4 SCREW 10-32 X 1/4" SOCKET HD 4 1
11 9072-4 LOCKNUT 1/4-20 NYLON 4 1
12 9073-4 LOCKNUT 1/4-20 NYLON-THIN 4 2
13 9074-4 WASHER 1/4" FLAT 1/2" OD 4 1
14 9075-4 WASHER 1/4" FLAT-THIN 4 5
15 9089-4 WASHER 5/16" FLAT 4 1
16 9115-4 SCREW 10-32 X 3/8 PHIL PAN HD 4 2
17 9042-4 SCREW 10-32 X 1/2" SET SCREW 4 1
18 5023-4 STEM BMPR FOR BACKPOST & ARMS 4 1
19a 5021 FOAM ARMREST PAD - 4 1/2" 1 1
19b 5022 FOAM ARMREST PAD - 9 1/2" 1 1
19c 10916 ARM PAD FULL LENGTH 13 1/4" 1 1
19d 10913 ARM PAD DESK LENGTH 9 1/4" 1 1
