Freedom NXT User Manual

140
FREEDOM DESIGNS, INC.
WPCNXT 62013
Appendix—Technical Specications
Freedom Designs Armrest Heights
Armrest Style Foam Desk Full
Flip Back 6.5”-11.5” 7.5”-12.5” 7.5”-12.5”
Flip Back Locking 6.5”-11.5” 7.5”-12.5” 7.5”-12.5”
Flip Back Telescoping 6.5”-11.5” 7.5”-12.5” 7.5”-12.5”
Flip Back Telescoping Locking 6.5”-11.5” 7.5”-12.5” 7.5”-12.5”
Single Post Height Adjustable Short N/A 8” - 14” 8” - 14”
Single Post Height Adjustable Tall N/A 10” - 16” 10” - 16”
Dual Post Fixed Height N/A 9.5” 9.5”
Dual Post Adjustable Height Flip Back N/A 9” - 13” 9” - 13”
Note: All heights from top of seat frame to top of armrest pad
NXT Footrest / Extension Lengths
Extension/Hanger 75° Pop 75° Lch 90° Pop 90 °Lch ELR (90°)
Hanger Only 6”-8” 5.5”-8.5” 4”-8” 4”-8” 6”-10”
High Mount N/A N/A 1.5”-3” N/A N/A
4” H D Ext. 9”-12” 9.5”-12.5” 9”-12” 9”-12” 13”-15”
6” H D Ext. 9”-15” 9.5”-15.5” 9”-15” 9”-15” N/A
4” Adjustable 10”-13” 9.5”-12.5” 11”-13” 10”-13” N/A
6” Adjustable 12”-15” 10.5”-14.5” 13”-15” 12”-15” N/A
8” Adjustable 14”-17” 12.5”-16.5” N/A N/A N/A
NXT MAPS Footrest / Extension Lengths
Extension/Hanger 75° Pop 75° Lch 90° Pop 90 °Lch ELR (90°)
Hanger Only 5.5”-7.5” 5”-8” 5.5”-7.5” 4.5”-7.5” 4.5”- 8.5” & 11.5”
High Mount N/A N/A N/A N/A N/A
4” H D Ext. 8.5”-11.5” 9”-12” 8.5”-11.5” 8.5”-11.5” 12.5”-15.5”
6” H D Ext. 8.5”-13.5” 9”-14” 8.5”-13.5” 8.5”-13.5” N/A
4” Adjustable 8.5”-11.5” 9”-12” 9.5”-11.5” 8.5”-11.5” N/A
6” Adjustable 10.5”-13.5” 10”-14” 11.5”-13.5” 8.5”-13.5” N/A
8” Adjustable 12.5”-15.5” 12”-16” N/A N/A N/A
Note: Length from top of footrest plate to top of seat rail.
Note: Without extensions bottom hanger hole not accessible for hardware.
Note: Heavy duty extensions do not telescope adjust. Footrests adjust vertically
in length on heavy duty extension tubes.
Dimensions & Specications
Frame Weight
(approximate)
22 lbs. complete (wheels, legrests, tubular armrests)
Tilt Range: -5º (anterior tilt on tall pivot frame) to 45º
Occupant Weight capacity All frames 225 lbs.
Overall Width at rear
wheels
frame width + 8.5” (9.5” with foot or hand activated
wheel locks)
Overall width at armrests frame width + 6”
Overall frame length
(approximate)
Short - 39” Medium - 44” Long - 48”

Freedom NXT Specifications

General

Weight Capacity	300 lbs
Legrests	Swing-away
Range	Up to 15 miles
Type	Power Wheelchair
Seat Width	18 inches
Seat Depth	16 inches
Motor	24V DC
Ground Clearance	3 inches
