FREEDOM DESIGNS, INC.
59
WPCNXT 62013
Frames—Base & Seat
FRAME SIZE PART NUMBER: FRONT FRAME DIMENSIONS: PART NUMBER: REAR FRAME DIMENSIONS:
SHORT 18300 SHORT 8.5” L 18310 SHORT 10.5”L X 8.5”H
MEDIUM LOW TILT 18301 MEDIUM 10.5” L 18311 MEDIUM - LOW TILT 10.5”L X 8.5”H
MEDIUM TALL TILT 18301 MEDIUM 10.5” L 18312 MEDIUM - TALL TILT 10.5”L X 10.5”H
LONG 18302 LONG 10.5” L 18313 LONG - TALL TILT 13”L X 10.5”H
See Page 37
1
2
3
9
14
7 5
4
7
14
12
13
11
6
10
12
8
14
16
15
