FREEDOM DESIGNS, INC.
65
WPCNXT 62013
Frame Growth Kits
See pages 59 & 62 for
seat rail options.
Individual side frame
components available
separately. See page
59 for parts.
FRAME GROWTH CHART
CURRENT FRAME SIZE: FRAME SECTION NEEDED:
MEDIUM LOW MEDIUM TALL LONG
F R S F R S F R S
SHORT FRAME
X X X X X X X X
MEDIUM LOW TILT
X X X
MEDIUM TALL TILT
X X
LONG FRAME
F
FRONT SIDE FRAME
REAR SIDE FRAME (INCLUDES TILT PIVOT)
SEAT RAILS
R
S
1
2
SIDE FRAMES
COMPLETE AS SHOWN
