FREEDOM DESIGNS, INC.

WPCNXT 62013

Tilt Mechanism—Dual Hand Activated Tilt (cont.)

POS. ITEM # DESCRIPTION QTY ASSY NOTES:

1 18090-2 DUAL HAND ACTIV TILT ASSY NXT 1 1 INCLUDES POS. 2-4, 7-13

2 12006 COMPOSITE TILT HANDLE 1 1

3 18100-1 NXT HAND TILT CABLE ASSY 1 1

4a 18091-L TILT MECH LOCK ONLY - NXT L 1 1

4b 18091-R TILT MECH LOCK ONLY - NXT R 1 1

4 18091-2 TILT MECH LOCK ONLY - NXT PR 2 1

5a 18092-L MECH LOCK MTG BRKT LWR NXT L 1 1 ALL FRAMES

5b 18092-R MECH LOCK MTG BRKT LWR NXT R 1 1 ALL FRAMES

5 18092-2 MECH LOCK MTG BRKT LWR NXT 2 1 ALL FRAMES

6a 18150-L MECH LOCK MTG BRKT UPR NXT L 1 1 TALL TILT FRAMES ONLY

6b 18150-R MECH LOCK MTG BRKT UPR NXT R 1 1 TALL TILT FRAMES ONLY

6 18150-2 MECH LOCK MTG BRKT UPR NXT 1 1 TALL TILT FRAMES ONLY

7 8997-4 RUBBER BUSHING - THIN 4 2

8 9035-4 SCREW 1/4-20X 1-1/2" BUTTON 4 1

9 9036-4 SCREW 1/4-20 X 1-3/4" BUTTON 4 1

10 9083-1 SCREW 5/16-18 X 2-3/4" HEX HD 1 1

11 9072-4 LOCKNUT 1/4-20 NYLON 4 2

12 9088-4 LOCKNUT 5/16-18 NYLOC-THIN 4 1

13 9074-4 WASHER 1/4" FLAT 1/2" OD 4 4
