FREEDOM DESIGNS, INC.
107
WPCNXT 62013
Wheel locks—Foot Activated Drum (cont.)
POS. ITEM # DESCRIPTION QTY ASSY NOTES:
1 18500-2 FOOT ACTIV DRUM W/L ASSY NXT 1 1 ALL WHEEL SIZES BEFORE 2/28/2013 / EFFECTIVE
3/1/2013 ALL BUT 16 & 18 WHEELS
1 18501-2 FT ACTV DRM W/L ASSY NXT 16/18 1 1 DRUM WHEEL LOCK 16 & 18” WHEELS ONLY
(EFFECTIVE 3/1/2013)
2 18510-1 FOOT LEVER ASSY - DRUM W/LOCK 1 1
3 18511-1 CABLE ACCESS COVER 1 2
4 9126-4 SCREW 10-32 X 3/8" BHCS 4 2
5 18512-1 CABLE ANCHOR PLATE STNLS 1 2
6 9127-4 SCREW 10-32 X 3/8" SOCKET 4 2
7 18513-1 CABLE FERRULE - SLOTTED 1 2
8 18514-1 FOOT LEVER MOUNTING BRACKET 1 1
9 18515-1 FT MECH MTNG BRKT SPCR 1 1
10 9021-4 SCREW 1/4-20 X 1-1/2" BHCS 4 1
11 9033-4 SCREW 1/4-20 X 1" BHCS 4 2
12 5016B FOAM GRIP 3/4" X 2"
13 18527-1 AXLE Q/R 4-5/8 X 1/2" DRUM LOC 1 1 FOR ALL WHEELS EFFECTIVE 3/1/2013
13 18527-2 AXLE Q/R 4-5/8 X 1/2" DRUM LOC 2 1 FOR ALL WHEELS EFFECTIVE 3/1/2013
14 18528-1 AXLE Q/R 5" X 1/2" DRUM LOC 1 1 DRUM BRAKE FOR 16 & 18" WHEELS ONLY UNTIL
2/28/2013
14 18528-2 AXLE Q/R 5" X 1/2" DRUM LOC 2 1 DRUM BRAKE FOR 16 & 18" WHEELS ONLY UNTIL
2/28/2013
15a 18530-L DRUM BRAKE & LOCK MECHANISM L 1 1
15b 18530-R DRUM BRAKE & LOCK MECHANISM R 1 1
15 18530-2 DRUM BRAKE & LOCK MECHANISM PR 1 1
16 18531-L DRUM BRAKE MECH MNTNG PLATE L 1 1
16 18531-R DRUM BRAKE MECH MNTNG PLATE R 1 1
17 18532-1 DRUM BRAKE AXLE PLATE 1 1
18a 18533-1 DRUM BRAKE AXLE SLEEVE 2-3/4" 1 1
18b 18534-1 DRUM BRAKE AXLE SLEEVE 2-1/4" 1 1 16 & 18" WHEELS ONLY / EFFECTIVE 3/1/2013
19 18535-1 AXLE SLEEVE SPACER 5/16 X 3/4" 1 1
20 9121-4 NUT 3/4-16 JAM NUT ZINC 4 1
21 18536-2 DRUM BRAKE - W/L SHOE SET 1 1 ONE SET DOES ONE WHEEL
22 18537-1 DRUM BRAKE SHOE RETURN SPRING 1 1
23 18538-1 DRUM BRAKE SHOE BACKING SPACER 1 1
24 18539-1 DRUM BRAKE SHOE CAM 1 1
25 18540-1 DRUM BRAKE SHOE CAM ARM 1 1
26 9122-4 SCREW 5MM X 8MM BHCS 4 1
27 18542-1 BRAKE SHOE RETAINER CLIP 1 1
28 18543-1 CABLE ANCHOR BOLT 1 1
29 9123-4 WASHER 6MM ID CHROME FLAT 4 2
30 9124-4 NUT 10MM CHROME LOCK NUT 4 1
31 18544-1 CABLE END ADJ FITTING - DRUM BRAKE 1 1 10MM WRENCH FOR ADJUSTMENT
Continued Next Page
