Freedom NXT - Page 33

24
FREEDOM DESIGNS, INC.
WPCNXT 62013
Axle Components (cont.)
POS. ITEM # DESCRIPTION QTY ASSY NOTES:
1a 18001-L NXT AXLE PLATE ASSY COMPL L 1 1 INCLUDES POS. 2a, 3-12
1b 18001-R NXT AXLE PLATE ASSY COMPL R 1 1 INCLUDES POS. 2b, 3-12
1 18001-2 NXT AXLE PLATE ASSY COMPL PR 2 1 INCLUDES POS. 2a, 2b, 3-12
2 18000-2 NXT AXLE PLATE WELDED PR 2 1
2a 18000-L NXT AXLE PLATE WELDED L 1 1
2b 18000-R NXT AXLE PLATE WELDED R 1 1
3 18002-1 NXT AXLE PLATE MTG BRKT 1 1
4 18003-1 NXT AXLE PLATE MTG BRKT CLMP 1 1
5 4001 AXLE Q/R 4-1/2" X 1/2" STD 1 1 STD FOR ALL WHEELS EXCLUDING HUB LOCK
6 2003 DOUBLE LOCK AXLE RECEIVER 1 1
7 1999A AXLE RECEIVER SPACER 1 1
8 9023-4 SCREW 1/4-20 X 2" HEX HEAD 4 2
9 9024-4 SCREW 1/4-20 X 2-1/4" HEX HD 4 1
10 9062-4 SCREW 1/4-20 X 1 1/4" SKT HEAD 4 2
11 9073-4 LOCKNUT 1/4-20 NYLON-THIN 4 3
12 9074-4 WASHER 1/4" FLAT 1/2" OD 4 6
13 9092-4 LOCKNUT 3/4-16 HEX JAM 4 1
