Freedom NXT - Page 41

32
FREEDOM DESIGNS, INC.
WPCNXT 62013
Dynamic Rocker Back OEM Parts (cont.)
POS. ITEM # DESCRIPTION QTY ASSY NOTES:
1 100311 Bearing, Idler Wheel 4 NOT SHOWN
2 502051-003-G DRB Backpost Lug - .740 2
3 502052-G DRB Actuator Arm 2
4 502055-001-A DRB Impact Spring - Yellow 50a
Polyurethane
2
4 502055-002-A DRB Impact Spring - Natural 60a
Polyurethane
4
4 502055-003-A DRB Impact Spring - Green 80a
Polyurethane
2
4 502055-004-A DRB Impact Spring - Blue 70a Polyurethane 2
5 502056-D DRB Backpost Lug Bushing 4
6 502057-E DRB Latch Plate 2
7 502058-C DRB Latch Plate Bushing 2
8 502059-C DRB Actuator Arm Cover Plate 2
9 502060-B DRB Actuator Shaft 2
10 502062-B DRB Impact Spring Cap 2
11 502073-001-E DRB Universal Housing 2
12 502074-001-B DRB Universal Bracket - HD 4
13 502076 M8 x 1.25 Steel Ball Plunger, Locking 2
14 502077-002 Socket Set Screw / M8 x 1.25 x 40mm /
Black Oxide
2
15 F0509 M5x12 SHCS Zinc 8.8 8
16 F0523 1/4-20 x 2” SOCKET HD 4
17 F0601 M6 Flat Washer, Zinc 4
18 F0605 M6 Lock Nut, Zinc 2
19 F0625 M6x30 SHCS, Zinc 4
20 F0632 M6x50 SHCS, Zinc 2
21 F0802 M8x1.25 Nylon Lock Nut Zinc Plated 2
22 F0803 M8 Flat Washer Plated 2
23 F1201 M12 Std Flat Washer - Zinc 2
24 F2002 1/2"x20 ESNA Lock Nut - Thin 2
25 9023-4 1/4-20 x 2” HEX HEAD 4
