FREEDOM DESIGNS, INC.
41
WPCNXT 62013
Cross Brace Components - Folding Frames
FRAME
WIDTH
CROSS
BRACE ARM
LENGTH “A”
CROSS BRACE
TUBE LENGTH
“A”
10-12 W 3-7/8” 9-3/16” (NOTCHED)
11-13 W 4-3/8” 9-3/4”
12-14 W 4-13/16” 10-1/8”
13-15 W 5-1/4” 11”
14-16 W 5-3/4” 11-1/4”
15-17 W 6-1/4” 11-13/16”
16-18 W 6-11/16” 12-11/16”
17-18 W 6-11/16” 12-11/16”
18W 6-11/16” 14-1/2”
19W 7-3/8” 15-1/2”
20W 7-5/8” 16-1/2”
4
20
13
8
11
1618
3
15
18
16
7
18
10
9
10
16
12
18
14
20
19
5
20
19
10
17
17
2
6
18
1
A
A
6
3
