52
FREEDOM DESIGNS, INC.
WPCNXT 62013
Footrests—MAPS (Multi Axis Positioning System) Cont.
POS. ITEM # DESCRIPTION QTY ASSY NOTES:
1 18243-L MAPS FOOTPLATE ASSY 10-11W L 1 1 INCLUDES POS. 3-16
1 18243-R MAPS FOOTPLATE ASSY 10-11W R 1 1 INCLUDES POS. 3-16
1 18243-2 MAPS FOOTPLATE ASSY 10-11W PR 2 1 INCLUDES POS. 3-16
1 18244-L MAPS FOOTPLATE ASSY 12-13W L 1 1 INCLUDES POS. 3-16
1 18244-R MAPS FOOTPLATE ASSY 12-13W R 1 1 INCLUDES POS. 3-16
1 18244-2 MAPS FOOTPLATE ASSY 12-13W PR 2 1 INCLUDES POS. 3-16
1 18245-L MAPS FOOTPLATE ASSY 14-15W L 1 1 INCLUDES POS. 3-16
1 18245-R MAPS FOOTPLATE ASSY 14-15W R 1 1 INCLUDES POS. 3-16
1 18245-2 MAPS FOOTPLATE ASSY 14-15W PR 2 1 INCLUDES POS. 3-16
1 18246-L MAPS FOOTPLATE ASSY 16-17W L 1 1 INCLUDES POS. 3-16
1 18246-R MAPS FOOTPLATE ASSY 16-17W R 1 1 INCLUDES POS. 3-16
1 18246-2 MAPS FOOTPLATE ASSY 16-17W PR 2 1 INCLUDES POS. 3-16
1 18247-L MAPS FOOTPLATE ASSY 18-20W L 1 1 INCLUDES POS. 3-16
1 18247-R MAPS FOOTPLATE ASSY 18-20W R 1 1 INCLUDES POS. 3-16
1 18247-2 MAPS FOOTPLATE ASSY 18-20W PR 2 1 INCLUDES POS. 3-16
2 18250-1 MAPS ASSY ONLY - NO FOOTPLATE 1 1 SEE PAGE 43 FOR FOOTPLATE
2 18250-2 MAPS ASSY ONLY - NO FOOTPLATE 2 1 SEE PAGE 43 FOR FOOTPLATE
3 FOOTPLATE ANG ADJ FTPLT SEE PAGE 43
4 18251-1 MAPS BALL PIVOT HANGER MOUNT 1 1 FRONT DRILLED 1" HANGERS ONLY
5 18252-1 MAPS BALL PIVOT 1 1
6 18253-1 MAPS BALL BASE 1 2 2 EACH NEEDED FOR MAPS ASSY
7 18254-1 MAPS MOUNTING PLATE 1 1
8 9110-4 SCREW 1/4-20 X 1-5/8" BTN HD 4 2
9 9046-4 SCREW 1/4-20 X 3/4" FLAT HEAD 4 2
10 9036-4 SCREW 1/4-20 X 1-3/4" BUTTON 4 1
11 8712-2 SCREW 5/16-18 x 1-3/4" FLAT HD 2 3
12 9072-4 LOCKNUT 1/4-20 NYLON 4 1
13 9073-4 LOCKNUT 1/4-20 NYLON-THIN 4 2
14 9087-4 LOCKNUT 5/16-18 NYLOC 4 3
15 9075-4 WASHER 1/4" FLAT-THIN 4 5
16 9090-4 WASHER 5/16" FLAT THIN 4 3
