Freenove ESP32-S3 User Manual

Any concerns?  support@freenove.com
105
Chapter 7 Camera Web Server
█ www.freenove.com
Add procedure files and API interface files related to ESP32-S3 camera.
1
2
…
9
…
11
#include "esp_camera.h"
#include <WiFi.h>
#define CAMERA_MODEL_ESP32S3_EYE // Has PSRAM
#include "camera_pins.h"
Enter the name and password of the router
13
14
const char *ssid = "********"; //input your wifi name
const char *password = "********"; //input your wifi passwords
Initialize serial port, set baud rate to 115200; open the debug and output function of the serial.
21
22
23
Serial.begin(115200);
Serial.setDebugOutput(true);
Serial.println();
Configure parameters including interface pins of the camera. Note: It is generally not recommended to change
them.
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
camera_config_t config;
config.ledc_channel = LEDC_CHANNEL_0;
config.ledc_timer = LEDC_TIMER_0;
config.pin_d0 = Y2_GPIO_NUM;
config.pin_d1 = Y3_GPIO_NUM;
config.pin_d2 = Y4_GPIO_NUM;
config.pin_d3 = Y5_GPIO_NUM;
config.pin_d4 = Y6_GPIO_NUM;
config.pin_d5 = Y7_GPIO_NUM;
config.pin_d6 = Y8_GPIO_NUM;
config.pin_d7 = Y9_GPIO_NUM;
config.pin_xclk = XCLK_GPIO_NUM;
config.pin_pclk = PCLK_GPIO_NUM;
config.pin_vsync = VSYNC_GPIO_NUM;
config.pin_href = HREF_GPIO_NUM;
config.pin_sscb_sda = SIOD_GPIO_NUM;
config.pin_sscb_scl = SIOC_GPIO_NUM;
config.pin_pwdn = PWDN_GPIO_NUM;
config.pin_reset = RESET_GPIO_NUM;
config.xclk_freq_hz = 20000000;
config.frame_size = FRAMESIZE_UXGA;
config.pixel_format = PIXFORMAT_JPEG; // for streaming
config.grab_mode = CAMERA_GRAB_WHEN_EMPTY;
config.fb_location = CAMERA_FB_IN_PSRAM;
config.jpeg_quality = 12;
config.fb_count = 1;
