Freenove ESP32-S3 User Manual

Any concerns?  support@freenove.com
71
Chapter 5 WiFi Working Modes
█ www.freenove.com
Project 5.2 AP mode
Component List & Circuit
Component List & Circuit are the same as in Project 5.1.
Component knowledge
AP mode
When ESP32-S3 selects AP mode, it creates a hotspot network that is separate from the Internet and waits
for other WiFi devices to connect. As shown in the figure below, ESP32-S3 is used as a hotspot. If a mobile
phone or PC wants to communicate with ESP32-S3, it must be connected to the hotspot of ESP32-S3. Only
after a connection is established with ESP32-S3 can they communicate.
Circuit
Connect Freenove ESP32-S3 to the computer using the USB cable.
