Freenove ESP32-S3 User Manual

Any concerns?  support@freenove.com
Chapter 8 Camera Tcp Server
136
www.freenove.com █
5
6
7
#define CAMERA_MODEL_ESP32S3_EYE
#include "camera_pins.h"
Set name and password for router that ESP32-S3 needs to connect to. And set ESP32-S3 to open two servers,
whose port are 8000 and 5000 respectively.
10
11
12
13
const char *ssid_Router = "********";
const char *password_Router = "********";
const char *ssid_AP = "********";
const char *password_AP = "********";
Enable ESP32-S3’s server function and set two monitor ports as 5000 and 8000. In general, the two port
numbers do not require modifications.
15
16
17
WiFiServer server_Cmd(5000);
WiFiServer server_Camera(8000);
extern TaskHandle_t loopTaskHandle;
Initialize serial port, set baud rate to 115200; open the debug and output function of the serial.
20
21
22
Serial.begin(115200);
Serial.setDebugOutput(true);
Serial.println();
Define a variable for camera interface and initialize it.
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
void cameraSetup() {
camera_config_t config;
config.ledc_channel = LEDC_CHANNEL_0;
config.ledc_timer = LEDC_TIMER_0;
config.pin_d0 = Y2_GPIO_NUM;
config.pin_d1 = Y3_GPIO_NUM;
config.pin_d2 = Y4_GPIO_NUM;
config.pin_d3 = Y5_GPIO_NUM;
config.pin_d4 = Y6_GPIO_NUM;
config.pin_d5 = Y7_GPIO_NUM;
config.pin_d6 = Y8_GPIO_NUM;
config.pin_d7 = Y9_GPIO_NUM;
config.pin_xclk = XCLK_GPIO_NUM;
config.pin_pclk = PCLK_GPIO_NUM;
config.pin_vsync = VSYNC_GPIO_NUM;
config.pin_href = HREF_GPIO_NUM;
config.pin_sscb_sda = SIOD_GPIO_NUM;
config.pin_sscb_scl = SIOC_GPIO_NUM;
config.pin_pwdn = PWDN_GPIO_NUM;
config.pin_reset = RESET_GPIO_NUM;
config.xclk_freq_hz = 20000000;
config.frame_size = FRAMESIZE_UXGA;
config.pixel_format = PIXFORMAT_JPEG; // for streaming
config.grab_mode = CAMERA_GRAB_WHEN_EMPTY;
config.fb_location = CAMERA_FB_IN_PSRAM;
