Freenove ESP32-S3 User Manual

Any concerns?  support@freenove.com
137
Chapter 8 Camera Tcp Server
█ www.freenove.com
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
config.jpeg_quality = 12;
config.fb_count = 1;
// if PSRAM IC present, init with UXGA resolution and higher JPEG quality
// for larger pre-allocated frame buffer.
if(psramFound()){
config.jpeg_quality = 10;
config.fb_count = 2;
config.grab_mode = CAMERA_GRAB_LATEST;
} else {
// Limit the frame size when PSRAM is not available
config.frame_size = FRAMESIZE_SVGA;
config.fb_location = CAMERA_FB_IN_DRAM;
}
// camera init
esp_err_t err = esp_camera_init(&config);
if (err != ESP_OK) {
Serial.printf("Camera init failed with error 0x%x", err);
return;
}
sensor_t * s = esp_camera_sensor_get();
// initial sensors are flipped vertically and colors are a bit saturated
s->set_vflip(s, 1); // flip it back
s->set_brightness(s, 1); // up the brightness just a bit
s->set_saturation(s, 0); // lower the saturation
Serial.println("Camera configuration complete!");
}
Loop function will constantly send camera data obtained to mobile phone APP.
60
61
62
63
64
65
66
67
68
69
70
71
72
while (client.connected()) {
fb = esp_camera_fb_get();
if (fb != NULL) {
uint8_t slen[4];
slen[0] = fb->len >> 0;
slen[1] = fb->len >> 8;
slen[2] = fb->len >> 16;
slen[3] = fb->len >> 24;
client.write(slen, 4);
client.write(fb->buf, fb->len);
esp_camera_fb_return(fb);
}
else {
