Freewing F-104 Starfighter - Page 5

Aileron pushrod size Aileron pushrod mounting hole
Flap pushrod size Flap pushrod mounting hole
4
Item No.:FJ310
F-104S Starfighter
Pushrod diameter:Ø1.5mm
1
2
3
4
5
1
2
3
1
2
3
4
5
1
2
3
A
B
C
E
D
F
Pushrods
1. Use a servo tester or radio to center the servo arm.
2. ;
3. Place the servo into the 17g servo box(C),and press the servo cable into the cable trough (F).
4. Place the 17g servo cover(B) over the servo and use 2 screws(A)to secure it.
5. Connect pushrod (E)to the servo arm and adjust its length so the control surface is in the neutral
position then snap it over the ball link on the rudder control horn(D).
Use glue to attach the 17g servo box(C) and control arm(D)to the elevator and rudder.
Servo
Elevator and rudder
Elevator and Rudder Servo Installation
Elevator pushrod size
Rudder pushrod size
Elevator pushrod mounting hole
Rudder pushrod mounting hole
EN
A-Screws
B-Servo cover
C-Servo box
D-Rudder horn
E-Rudder pushrod
F-Servo cable trough
（PWA2x8mm 4pcs）
Pushrod diameter:Ø1.5mm
Servo arm
Servo arm
58mm
(2.28 in)
80mm
(3.15 in)
1
2
4
5
70mm
(-2/3")2
2
3
1
2
3
4
5
70mm
(2-2/3")
2
3
3
Pushrod diameter:Ø1.5mm
Pushrod diameter:Ø1.5mm
Servo arm
Servo arm
R
