Slat Assembly
D2
A- Slat pushrod
B - Metal pin
C - E-clip
1.Use "Metal pin(B)" and "E-clip(C)" to attach
one side of the slat pushrod to the slat
controller, use "Screw(D)" to attach the other
side to the plastic slat.
"
m
"
"
"
"
"
"P
"
m
h
Attention:Slat assembly has 6 pieces.
Please refer to the letter in the plastic to
distinguish: L and R refer to the Left and
Right main wing, Figures 1-3 mean the
direction from wing root to wingtip
.
Attention:
After inserting the plastic pin, melt the other
side using a hot tip such as a soldering iron.
Attention:
The slat controller has a left and
right side, please distinguish between the two
1.Use the screws and glue to attach
the assembled slat sets.
2.Use glue to attach the blister cover to
k
eep the surface clean.
Nose Gear Assembl
y
Assemble/disassemble the nose gear
b
y
referring to the following diagrams.
Step 1
T-45 Goshawk
K�
Step2
Accessories name and specifications
A
-
Electronic retract
B -E-clip (02.0mm)
C -Retract pin
D
-
Steering tiller arm
E
-
Steering rod ring
F
-
Steering rod
G-Screw (M3x3mm)
H -Spring
I -Screw (PM2x4mm)
J -Main gear strut
K -Shock absorbing rod
L - Connecting arm 1
M
-Screw (M3x5.2mm)
N
-Grub screw(M4x4mm)
0 - Nose wheel axle
P -Wheel
(045115mm)
Q
-Washer
R -
Connect ing arm 2
S -Screw (PA2x8mm)
T -Plastic retract rod
U -Plastic launching hook
V -Shock absorber supporting rod 2
W -Shock absorber supporting rod 1
x -Pin
Y -Pin
Z - Pin
AA -Pin
AB -Collar
AC -LED landing light
y
u-►
y
Step 3
Step4
-7-
Screws (
PB2. 6x6mm 16pcs )
Refer to the photo on the right
