freightliner Sprinter Owner's Manual

Fuse block F55/4
No. Consumer Fuse
rating
10 Terminal 30, body/
equipment
manufacturer
25 A
11 Terminal 15, body/
equipment
manufacturer
15 A
12 D+, body/equipment
manufacturer
10 A
13 Fuel pump (FSCM)
Fuel pump relay
20 A
15 A
14 Trailer power socket 20 A
15 Trailer recognitionunit 25 A
16 Tire pressure monitor/
PARKTRONIC
7.5 A
17 PSM control unit 25 A
18 PSM control unit 25 A
Fuse block F55/5
No. Consumer Fuse
rating
19 Overhead control panel
withoutATA and without
rain sensor
5 A
Overhead control panel
with ATA
25 A
Overhead control panel
with rain sensor
25 A
20 License plate lamp
(courier vehicles)/
perimeter lamp/
entrance lighting (bus)
7.5 A
No. Consumer Fuse
rating
21 Terminal 30, body
electrics (courier
vehicles)
15 A
Rear window defroster
without ATA
30 A
Rear window defroster
with ATA
15 A
22 Electrical step, co-
driver's door (bus)
10 A
Rear window defroster 2 15 A
Vehicle socket (courier
vehicles)
20 A
23 Electric system: non-MB
body
12 V left rear socket,
load/ passenger
compartment
10 A
15 A
24 12 V socket under the
base of driver's seat
15 A
25 12 V socket rear right,
cargo compartment/
passenger compartment
15 A
26 Hot-water auxiliary
heating
25 A
27 Auxiliary warm-air heater
Heater booster system
20 A
25 A
Fuses supplement
9
Z
