Fuse block F55/6
No. Consumer Fuse
rating
28 Starter auxiliary battery/
starterrelay power
supply
25 A
29 Terminal 87 (7), gas
system, vehicles with a
natural gas engine
(NGT)
1
7.5 A
SCR
2
control unit,
vehicles with exhaust
gas aftertreatment
10 A
Terminal 30, all-wheel
drive, control unit
30 A
30 Auxiliary heat exchanger
fan
15 A
Brake booster 30 A
31 Sliding door closing
assistance, left
15 A
Electric sliding door, left 30 A
Rear compartment
heating blower
30 A
32
SCR
2
relay supply,
vehicles with exhaust
gas aftertreatment
5 A
KEYLESS ENTRY 10 A
33 Sliding door closing
assistance, right
15 A
Electric sliding door,
right
30 A
Level control (ENR)
control unit
30 A
Compressor air
suspension
30 A
No. Consumer Fuse
rating
34
SCR
2
heater 3 DEF
supply reservoir,
vehicles with exhaust
gas aftertreatment
15 A
35
SCR
2
heater 2hose,
vehicles with exhaust
gas aftertreatment
15 A
36
SCR
2
heater 1delivery
pump, vehicles with
exhaust gas
aftertreatment
10 A
Fuse block F55/7
No. Consumer Fuse
rating
37 Unassigned —
38 Unassigned —
39 Body electrics (courier
vehicles)
7.5 A
Passenger compartment
air-conditioning system
7.5 A
Roof ventilator 15 A
Siren 15 A
40 Unassigned —
41 Unassigned —
42 Rear-compartment air-
conditioning system
30 A
43 Electrical step, sliding
door, right
10 A
44 Electrical step, sliding
door, left
10 A
45 Electrical step, control
system
5 A
1
Natural Gas Technology.
2
Selective Catalytic Reduction.
10
Fuses supplement
