freightliner Sprinter Owner's Manual

No. Consumer Fuse
rating
15 Headlamp range
control/front-
compartment heating
5 A
16 Terminal 87 (3) 10 A
17 Air bag control unit 10 A
18 Terminal 15 vehicle/
brake light switch
7.5 A
19 Interiorlighting 7.5 A
20 Co-driver's door power
window switch/terminal
30/2 SAM (signal
acquisition and
actuation module)
25 A
21 Engine control unit 5 A
22 Brake system (ABS) 5 A
23 Terminal 87 (6), starter 10 A
24 Diesel engine, engine
components/control
unit, vehicles with a
natural gas engine NGT
1
10 A
25 12 V socket in the center
console
25 A
Fuse block F55/1
No. Consumer Fuse
rating
1 Driver's door control unit 25 A
2 Diagnostics connection 10 A
3 Brake system (valves) 25 A
4 Brake system (delivery
pump)
40 A
5 Terminal 87 (2a), engine 10 A
6 Terminal 87 (1a), engine 10 A
No. Consumer Fuse
rating
7 Headlamp cleaning
system
30 A
8 Anti-theft alarm system
(ATA)/beacon/beacon
with siren
15 A
9 Additional turnsignal
module
10 A
Fuse block F55/2
No. Consumer Fuse
rating
10 Radio
Radio NTG 2.5
15 A
20 A
11 Mobile phone/
tachograph/additional
recorder
7.5 A
12 Blower, front/auxiliary
heating blower setting 1
30 A
13 Auxiliary heating system
digital timer, radio
receiver/DIN slot basic
wiring/FleetBoard/anti-
theft protection with
vehicle tracking
7.5 A
14 Seat heating 30 A
15 Brake system control
unit
5 A
16 Heating, rear
compartment heating/
air conditioning, front/
CD changer
10 A
17 Motion detector 7.5 A
1
Natural Gas Technology.
Fuses supplement
5
Z
