300mm
Installation
3. Mount the toilet to the
floor with four screws
ST4.5*55mm.
4. Connecting the water hose.
Length from the last fixed point: 300mm
Diameter Inside: 10mm Outside: 16.5mm
Required torque (for a plywood floor): 1.2±0.3N.m.
Torque may differ if the floor is made from a different material.
Make sure after the hose is connected, the waste-holding tank can still be pulled out of the
toilet seat and removed.
Min.: 0.35bar at 4.2L/min
Max.: 0.70bar at 7.1L/min
8bar
Required pressure
Maximum allowable
pressure
14
