If you want to continue using your toilet after emptying the waste-holding tank, prepare the
waste-holding tank again. See Before use.
01 02 03
The waste-holding tank has liquid level indicator and water full alarm. When the left light on the
control panel blinks red, you will hear a series of beeps by pressing the flushing button, it means
the waste-holding tank is too full and must be emptied. When the alarm sound appears, the flushing
button will stop after 5s delay. (If less than 5s, can be used up to 2 times).
Emptying the waste-holding tank
Emptying the waste-holding tank:
04 05 06
+3L
To prevent water leaking damaging your caravan, do not travel with a waste-holding
tank that is more than 3/4 full.
06
