FREUCAMP W5000 - Toilet Installation; Mounting and Securing

Installation
1. Install the
shower tray
(if applicable).
59
50
50
5.3
10
2. Mount the wall bracket to the outside wall with three screws ST4.2*13mm, connecting the toilet
to the wall bracket.
Recommended distance between the wall bracket screws and the installation floor: 518mm
(The actual installation may need to adjust the position appropriately).
Unit: mm
Unit: mm
13
