19
5. FRIAMAT
®
prime eco
5.1 Description of function buttons
The FRIAMAT
®
prime eco has 7 function buttons.
MENU:
The MENU button is grey. It calls up the
main menus with its submenus (see also section 5.2
“Menu Layout”). In addition pressing the MENU
button will clarify an error following an error
message.
ST
ART: The START button is green. It starts up the
fusion process, selects submenus or individual
menus and saves settings. In addition this button is
used to confirm error messages/warning messages/
hints and tips in the display.
STOP:
The STOP button is red. The STOP button is
used to cancel the fusion process, to leave the sub
menus or individual menus and to terminate an
inputting process (without saving it). If you keep the
STOP button pressed for a longer period, regardless
in which submenu you are navigating, you will return
to the main screen “ CODE”.
Arr
ow buttons: The arrow buttons are blue. The
arrow buttons (up/down) are used to “browse”
through sub or individual menus. The arrow buttons
(left/right) are used to move the cursor from left to
right and back when entering alphanumeric symbols
(e.g. emergency input, date). Use the arrow buttons
(up/down) to select the required symbol (letter,
number, special symbol) at the appropriate place.
IMPOR
TANT!
There are some areas of the submenu where it is
not possible to see all the information in the
display at once. You will notice the „
“
-symbol in
the bottom display line. The blue arrow buttons
(up/down) will allow you to move about within
this menu areas and call up further information
into the display.
FT_2377e_II_07_GB.qxd 13.02.2007 12:31 Uhr Seite 19
