FRICK QUANTUM™ CONDENSER/VESSEL CONTROL PANEL S90-555 M
MAINTENANCE Page 15
A
nalog Input 1 - Condenser Pressure
A
nalog Input 1 Sensor Wiring
Input Function JP8 JP9 Connector Function
0 – 5 VDC * Out * Out * J4-10 +12 VDC
Resistance 1 - 2 Out J4-11 Input Signal
4 – 20 ma Out 1 – 2 J4-12 GND
ICDT 2 - 3 Out
Analog Input 2 - Outside Air Temperature
A
nalog Input 2 Sensor Wiring
Input Function JP18 JP19 Connector Function
0 – 5 VDC Removed Removed J4-7 +12 VDC
Resistance 1 - 2 Removed J4-8 Input Signal
4 – 20 ma Removed 1 – 2 J4-9 GND
ICDT * 2 - 3 * Removed *
Analog Input 3 - Outside Air Humidity
A
nalog Input 3 Sensor Wiring
Input Function JP10 JP11 Connector Function
0 – 5 VDC Removed Removed J4-4 +12 VDC
Resistance 1 - 2 Removed J4-5 Input Signal
4 – 20 ma * Removed * 1 – 2 * J4-6 GND
ICDT 2 - 3 Removed
Analog Input 4 - Condenser Drain Temp. (Refrigerant)
A
nalog Input 4 Sensor Wiring
Input Function JP20 JP21 Connector Function
0 – 5 VDC Removed Removed J4-1 +12 VDC
Resistance 1 - 2 Removed J4-2 Input Signal
4 – 20 ma Removed 1 – 2 J4-3 GND
ICDT * 2 - 3 * Removed *
Analog Input 5 - Future
A
nalog Input 5 Sensor Wiring
Input Function JP12 JP13 Connector Function
0 – 5 VDC Removed Removed J5-10 +12 VDC
Resistance 1 - 2 Removed J5-11 Input Signal
4 – 20 ma * Removed * 1 – 2 * J5-12 GND
ICDT 2 - 3 Removed
Analog Input 6 - Future
A
nalog Input 6 Sensor Wiring
Input Function JP22 JP23 Connector Function
0 – 5 VDC Removed Removed J5-7 +12 VDC
Resistance 1 - 2 Removed J5-8 Input Signal
4 – 20 ma * Removed * 1 – 2 * J5-9 GND
ICDT 2 - 3 Removed
Analog Input 7 - Future
A
nalog Input 7 Sensor Wiring
Input Function JP14 JP15 Connector Function
0 – 5 VDC Removed Removed J5-4 +12 VDC
Resistance 1 - 2 Removed J5-5 Input Signal
4 – 20 ma * Removed * 1 – 2 * J5-6 GND
ICDT 2 - 3 Removed
Analog Input 8 - Future
A
nalog Input 8 Sensor Wiring
Input Function JP24 JP25 Connector Function
0 – 5 VDC Removed Removed J5-1 +12 VDC
Resistance 1 - 2 Removed J5-2 Input Signal
4 – 20 ma * Removed * 1 – 2 * J5-3 GND
ICDT 2 - 3 Removed
