FRICK QUANTUM™ CONDENSER/VESSEL CONTROL PANEL S90-555 M
MAINTENANCE Page 3
Rs-485 Communications ______________________________________________________ 59
Rs-422 Communications ______________________________________________________ 59
Rs-232 Communications ______________________________________________________ 59
Quantum™ 4 Communications Wiring Diagrams ______________________________________ 60
Rs-485 Communications ______________________________________________________ 60
Rs-422 Communications ______________________________________________________ 60
Rs-232 Communications ______________________________________________________ 60
Convenser/Vessel Recommended Spare Parts __________________________________________ 61
Quantum™ Control Panel ________________________________________________________ 61
Remote Panel _________________________________________________________________ 61
Display Assembly Component Replacement Guide ____________________________________ 61
QUANTUM™ PUBLICATIONS
S90-555 CS Frick Quantum™ Condenser/Vessel Control
Panel COMMUNICATIONS SETUP (setup
and wiring for data communication using
available protocols)
S90-555 O Frick Quantum™ Condenser/Vessel Control
Panel OPERATION
E90-555 SD Frick Quantum™ Condenser/Vessel Control
Panel SETPOINT DATA SHEETS
Indicates an imminently
hazardous situation which, if not
avoided, will result in death or
serious injury.
Indicates a potentially hazardous
situation or practice which, if not
avoided, will result in death or
serious injury.
Indicates a potentially hazardous
situation or practice which, if not
avoided, will result in damage to
equipment and/or minor injury.
NOTE: Indicates an operating procedure, practice, etc., or
portion thereof which is essential to highlight.
CAUTION
!
WARNING
!
DANGER
!
