QUANTUM™ LX CONDENSER/VESSEL REPLACEMENT PARTS (Page 1 of 2)
Q5 Operator Interface Panel
Frick Number SAP Number Description
Circuit Breakers
639A0206H05 484047 5 Amp circuit breaker
Control Power
639A0185H10 483963 2-Pos. Selector Switch (Control Power)
639A0185H30 483966 Latch, 3 Across (Attaches contact block to switch mechanism)
Q5 Display Kit (Indoor LED)
639D0230G01 865280
Display Assembly includes:
Display, standard LED
LVDS to VGA Converter (Bat Wing board)
Display Cable Assembly
LED Backlight Harness
Hardware
Q4 Display Kit (Indoor LED)
639D0215G01 913882
Display Assembly includes:
Display (Cannot be ordered separately)
Mounting plate
Display Harness
Hardware
Flash Cards and Software
649A1113Gxx 901353 Program Flash Card (the xx indicates program version)
649A1063G99 485995 Quantum™ LX Setpoint Saver (USB Drive)
Harnesses
639D0218H01 850941 DC power and communications harness
639D0191H02 696514 Keypad and Communications cable kit
Keypads
640D0186H01 484621 Keypad/overlay with Frick
®
logo (Quantum™ LX)
Power Supplies
639B0115H02 642308 12 VDC power supply
Quantum™ Controllers
649C1152G01 686440 Q5 Board (Advantage)
639B0116H01 677556 Q5 Interface Communications Board
