SPECIFICATIONS
Product Specications 18k, 24k and 36k
Model No. Unit FPHW183/A FPHW243/A FPHW363A FPHW363B
INDOOR MODEL FPHFW18A3A,/ B FPHFW24A3A/B FPHSW36A3A/B FPHSW36A3C
OUTDOOR MODEL FPHSR18A3A FPHSR24A3A FPHSR36A3A FPHSR36A3B
CAPACITY COOLING (RATED) Btu 18000 23500 36000 35000
CAPACITY COOLING MIN - MAX Btu 6500-19500 8000-26500 12000--38000 12000--38000
COOLING AMPS 6.3 8.3 18.5 18.5
HEATING AMPS 7.2 11.1 16 16
SENSIBLE HEAT RATIO 80% 76% 79% 79%
CAPACITY HEATING (RATED) @ 47°F Btu 19000 26000 36000 35000
CAPACITY HEATING MIN - MAX Btu 6500-20000 8000-26500 12000--38000 12000--38000
CAPACITY HEATING (RATED) @ 17°F Btu 11600 14500 18700 18700
COP 3.40 3.05 3.05 2.93
HSPF 11.6 10.5 8.8 8.8
SEER 23.3 21 16.4 16.4
EER 13 12.5 8.6 8.33
MOISTURE REMOVAL Pts/h 3.2 5.1 6.8 6.8
AIRFLOW (HIGH/MED/LOW/QUIET) CFM 618/565/482/382 735/665/559/441 1030/824/706/588 1030/824/706/588
SOUND RATING - INDOOR (HIGH/MED/LOW/QUIET) dB-A 45/41/37/34 47/42/36/33 50/45/40/38 50/45/40/38
SOUND RATING - OUTDOOR dB-A 55 58 60 60
OPERATING RANGE (HEATING) °F -4° – 75° -4° – 75° -4° – 75° -4° – 75°
OPERATING RANGE (COOLING) °F 5° – 115° 5° – 115° 5° – 115° 5° – 115°
ELECTRICAL DATA
POWER SOURCE V/Hz/Phase 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P
MIN. AMPACITY A 15 20 30 30
COOLING WATTS W 1385 1880 4186 4186
HEATING WATTS W 1638 2500 3459 3459
MAX. TD FUSE/ BREAKER A 20 30 35 35
POWER AND COMMUNICATION CABLE Type 4 x 14AWG, 600V
THHN
4 x 14AWG, 600V
THHN
4 x 14AWG, 600V
THHN
4 x 14AWG, 600V
THHN
REFRIGERATION SYSTEM
REFRIGERANT R410a R410a R410a R410a
COMPRESSOR TYPE Rotary Rotary Rotary Rotary
CONNECTIONS Flare Flare Flare Flare
LIQUID LINE O.D. in 1/4 3/8 3/8 3/8
SUCTION LINE O.D. in 1/2 5/8 5/8 3/4
REFRIGERANT CHARGE . oz 54.7 66.3 81.2 81.2
FACTORY PRECHARGE ft. 25 25 25 25
MIN. / MAX. LINE LENGTH ft 10-66 10-66 10-66 10-66
MAX. HEIGHT DIFFERENCE ft 33 33 33 33
DIMENSIONS & WEIGHT
INDOOR UNIT
W x H x D in 45 3/16 x 13 1/8 x 9 15/16 50 5/8 X 13 5/8 X
10 5/16
50 5/8 X 13 5/8 X
10 5/16
NET WEIGHT lbs 33 33 40 40
SHIPPING WEIGHT lbs 38.5 38.5 48 48
OUTDOOR UNIT
W x H x D in 33 7/8 x 25 9/16 x
12 3/16
34 7/8 x 31 5/16 x
14 3/8
34 7/8 x 31 5/16 x
14 3/8
34 7/8 x 31 5/16 x
14 3/8
NET WEIGHT lbs 99 123.5 141
Figure 202
