A. IMPORTANT SAFETY AND GENERAL INFORMATION
A.4.1 Unpacking Instructions
(Small and Medium Chassis)
STEP 1. Cut all 4 packing straps.
STEP 2. Remove wooden shipping bar dividers.
STEP 3. Remove top foam pads.
STEP 4. Slowly remove outer box, careful not to loosen decorative front.
STEP 5. Slide the front forward.
STEP 6. Carefully lift decorative front box from foam front support.
STEP 7. Remove decorative front and set safely aside.
STEP 1
STEP 2
STEP 3
STEP 4
STEP 7
STEP 6
STEP 5
STRAPS x4
STEP 7
A.4.2 Unpacking Instructions
(Large Chassis)
Figure A.4.1 Figure A.4.2
STEP 1
STRAPS x4
STEP 1. Cut all 4 packing straps.
STEP 2. Slowly remove outer box, careful not to loosen decorative front.
STEP 3. Remove pad top.
STEP 4. Remove top board assembly.
STEP 5 Remove spacer.
STEP 6. Remove shipping top.
STEP 7. Remove Shipping Corners
STEP 8. Remove Shell liner.
STEP 9. Remove decorative front, vent foam support blocks,and set safely
aside.
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
STEP 7
STEP 8
STEP 9
