PARTS LIST
INDOOR UNIT
Ref. Ord.
No MW09C1F MW12C1F Q'ty
1 AIR FILTER 67201200 67201200
4 FRONT PANEL COMPLETE 67201201 67201201
6 INTAKE GRILLE ASSY 67201202 67201202
7 GRILLE CLAMP 67200936 67200936
8 LOUVER U 67201203 67201203
9 LOUVER Z 67201204 67201204
10 LOUVER HOLDER 67201205 67201205
11 GEAR-A 67201206 67201206
12 CASING ASSY 67201207 67201207
13 CASING COVER-F 67201208 67201208
14 CASING COVER-B 67201209 67201209
15 CROSS FLOW FAN ASSY 67201210 67201210
18 SHAFT HOLDER-C 67200922 67200922
19 DRAIN HOSE ASSY 67200913 67200913
20 DRAIN CAP ASSY 67201211 67201211
22 SWITCH BOX ASSY 67201212 67201212
23 BOX SWITCH
24 EVAPORATOR ASSY 67201214 67201214
25 EVAPORATOR SEAL
26 JOINT PIPE ASSY 67201216 67201216
27 INSULATION ( PIPE) E 67201217 67201217
28 HOLDER (EVAP)-L 67201218 67201218
29 HOLDER (EVAP)-R 67201219 67201219
30 WATER SEAL 67201220 67201220
31 EVAPORATOR BRACKET 67201221 67201221
32 TERMINAL 67201222 67201222
33 CONTROLLER PCB ASSY 67201223 67201231
34 DISPLAY PCB ASSY
67201224 67201224
38 STEP MOTOR 67201225 67201225
39 FAN MOTOR 67201226 67201226
40 REMOTE CONTROL 67201227 67201227
41 GRILLE GUARD 67201228 67201228
42 BUSHING 67201229 67201229
43 FRONT PANEL 67201230 67201230
44 REMOTE CONTROL HOLDER 67203202 67203202
Part No.
Description
2006.06.09 1
To Next Page
