Friedrich MR09C1F Service Manual

12006.03.13
SPECIFICATIONS
INDOOR UNIT
MW09C1F MW12C1F
OUTDOOR UNIT
MR09C1F MR12C1F
COOLING CAPACITY
9,700 BTU/hr 12,300 BTU/hr
POWER SOURCE
115 V 115 V
FREQUENCY
60 Hz 60 Hz
RUNNING CURRENT
7.6 A 9.8 A
INPUT WATTS
820 W 1,060 W
SEER
14.3 13.5
MOISTURE REMOVAL
2.1 Pts/hr (1.0 L/hr) 3.2 Pts/hr (1.5 L/hr)
AIR CIRCULATION-HIGH
560 m
3
/hr 660 m
3
/hr
ELECTRICAL DATA
COMPRESSOR
FAN MOTOR
DIMENSIONS
TYPE
Hermetic type, Permanent split condenser,
2 pole, Single phase, Induction motor
DISCRIMINATION
POWER SOURCE
EA89X1C-1FZDU1 EA118X1C-1FZDU1
115V 60Hz 115V 60Hz
REFRIGERANT R-410A
1 lb.9 oz ( 700 g ) 2 lb. 2 oz ( 950 g )
POWER SOURCE
115 V 115 V
HIGH
1,250 r.p.m.
1,100 r.p.m.
950 r.p.m.
800 r.p.m.
640 r.p.m.
1,450 r.p.m.
1,250 r.p.m.
1,050 r.p.m.
850 r.p.m.
770 r.p.m.
INDOOR UNIT
MED
LOW
QUIET
OUTDOOR UNIT
INDOOR UNIT HxWxD
HxWxD
10-13/16 x 31-1/8 x 9-7/16 inch
OUTDOOR UNIT
WEIGHT
INDOOR UNIT Gross / Net
Gross / Net
26 / 20 lbs. (12/9kg)
OUTDOOR UNIT
77 / 68 lbs. (35 / 31 kg ) 86 / 77 lbs. (39 / 35 kg )
275 x 790 x 215 mm
21-1/4 x 31-1/8 x 11-7/16 inch
540 x 790 x 290 mm
