Models :
MW09C1F / MR09C1F
MW12C1F / MR12C1F
OUTLINE AND DIMENSIONS
INDOOR UNIT
Unit : inch (mm)
OUTDOOR UNIT
31-1/8" (790)
2-3/16"
(56)
11/16"
(17)
21-1/4" (540)
14" (356)
11-7/16" (290)
11-3/16" (288)
22006.03.13
10-13/16 (275)
31-1/8 (790)
8-7/16
(215)
