Friedrich MRM09Y1J Service Manual


Technical Information
6HUYLFH0DQXDO
6SHFL¿FDWLRQV
6SHFL¿FDWLRQ6KHHW
Model
MWM09Y1J
MRM09Y1J
MWM12Y1J
MRM12Y1J
Product Code CB146035101_L13396 CB146035001_L13396
Power
Supply
Rated Voltage V~ 115 115
Rated Frequency Hz 60 60
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity (Min~Max) Btu/h 9000(3500~11000) 11800(3300~12500)
Heating Capacity (Min~Max) Btu/h 9800(2500~11000) 13000(3400~13500)
Cooling Power Input (Min~Max) W 750(220~1100) 1260(260~1340)
Heating Power Input (Min~Max) W 830(230~1230) 1320(250~1360)
Cooling Power Current A 9 15
Heating Power Current A 9.5 15.5
Rated Input W 1230 1360
Rated Current A 17.0 18.2
Air Flow Volume(SH/H/M/L/SL) CMF 330/277/224/188/- 341/288/235/200/-
Dehumidifying Volume Pint/h 1.69 2.96
EER (Btu/h)/W 12 9.4
COP (Btu/h)/W 12 9.8
SEER (Btu/h)/W 16 16
HSPF (Btu/h)/W 8.6 8.6
Application Area yd
2
14.4-21.5 19.14-28.7
Indoor
Unit
Model of indoor unit MWM09Y1J MWM12Y1J
Product Code CB146N35100_L13396 CB146N35000_L13396
Fan Type Cross-flow Cross-flow
Diameter Length(DXL) inch Φ3 5/8X23 3/8 Φ3 5/8X23 3/8
Fan Motor Cooling Speed (SH/H/M/L/SL) r/min 1300/1100/900/700/- 1350/1150/950/750/-
Fan Motor Heating Speed (SH/H/M/L/SL) r/min 1300/1150/980/820/- 1350/1200/1000/850/-
Output of Fan Motor W 15 15
Fan Motor RLA A 0.38 0.38
Fan Motor Capacitor μF 4 4
Input of Heater W / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter inch Φ2/7 Φ2/7
Row-fin Gap inch 2-1/18 2-1/18
Coil Length (LXDXW) inch 24X17/18X11 4/7 24X17/18X11 4/7
Swing Motor Model MP24BA MP24BA
Output of Swing Motor W 2.4 2.4
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 41/37/35/32/- 43/39/35/32/-
Sound Power Level (SH/H/M/L/SL) dB (A) 51/47/45/42/- 53/49/45/42/-
Dimension (WXHXD) inch 30 1/3X11 1/7X8 30 1/3X11 1/7X8
Dimension of Carton Box (LXWXH) inch 33 2/9X13 1/2X10 2/7 33 2/9X13 1/2X10 2/7
Dimension of Package (LXWXH) inch 33 1/3X13 4/7X10 6/7 33 1/3X13 4/7X10 6/7
Net Weight lb 19 19
Gross Weight lb 23 23
