Friedrich MRM09Y1J Service Manual


Installation and Maintenance
6HUYLFH0DQXDO
Above data is subject to change without notice.
No.
Description
Part Code
Qty
MWM09Y1J MWM12Y1J
1
Front Panel 69700336 69700336
1
2
Filter Sub-Assy 69700337 69700337
2
3
Screw Cover 69700338 69700338
1
4
Membrane 69700339 69700339
1
5
Front Case Assy 69700340 69700340
1
6
Guide Louver 69700341 69700341
1
7
Helicoid Tongue 69700342 69700342
1
8
Air Louver 69700330 69700330
2
9
Shaft of Guide Louver 69700343 69700343
2
10
Drainage Pipe Sub-assy 69700344 69700344
1
11
Rear Case assy 69700345 69700345
1
12
Wall Mounting Frame 69700346 69700346
1
13
Motor Sub-Assy 69700347 69700347
1
14
Motor Press Plate 69700348 69700348
1
15
Cross Flow Fan 69700349 69700349
1
16
Evaporator Assy 69700350 69700350
1
17
Temp Sensor Sleeving 69700351 69700351
1
18
Evaporator Support 69700352 69700352
1
19
Fan Bearing 68700159 68700159
1
20
Bearing Holder 69700353 69700353
1
21
Axil Bush Sub-assy 69700354 69700354
1
22
Electric Box Assy 69700364 69700355
1
23
Electric Box Cover Sub-Assy 69700356 69700356
1
24
Shield Cover 69700357 69700357
1
25
Crank 69700358 69700358
1
26
Stepping Motor 69700359 69700359
1
27
Indicator Shield Cover 69700293 69700293
1
28
Indicator Light Cover 69700294 69700294
1
29
Display Board 69700295 69700295
1
30
Electric Box Sub-Assy 69700365 69700360
1
31
Main Board 69700361 69700361
1
32
Terminal Board 69700130 69700130
1
33
Remote Controller 69700313 69700313
1
34
Temperature Sensor 69700362 69700362
1
35
Temperature Sensor 69700363 69700363
1
