Part 2 Product data_Outdoor units
7. Capacity tables
Models : MR36TQY3JMA
Cooling capacity
n Mixed type indoor unit
14 29.41 1.57 31.24 1.62 33.06 1.68 34.38 1.70 36.71 1.73 38.54 1.77
20 29.39 1.59 31.21 1.65 33.04 1.71 34.35 1.73 36.69 1.76 38.51 1.79
25 29.36 1.61 31.19 1.67 33.01 1.73 34.33 1.75 36.66 1.78 38.48 1.82
30 29.34 1.63 31.16 1.69 32.99 1.76 34.30 1.78 36.63 1.81 38.45 1.85
35 29.32 1.66 31.14 1.72 32.96 1.78 34.28 1.80 36.60 1.83 38.42 1.87
40 29.30 1.68 31.12 1.74 32.94 1.80 34.25 1.82 36.57 1.86 38.39 1.90
45 29.27 1.70 31.09 1.76 32.91 1.83 34.22 1.85 36.55 1.88 38.36 1.92
50 29.25 1.72 31.07 1.79 32.89 1.85 34.20 1.87 36.52 1.91 38.34 1.95
55 29.23 1.75 31.04 1.81 32.86 1.88 34.17 1.90 36.49 1.93 38.31 1.97
60 29.21 1.77 31.02 1.83 32.83 1.90 34.14 1.92 36.46 1.96 38.28 2.00
65 29.18 1.79 31.00 1.86 32.81 1.92 34.12 1.95 36.43 1.98 38.25 2.02
70 29.16 1.81 30.97 1.88 32.78 1.95 34.09 1.97 36.41 2.01 38.22 2.05
75 28.46 1.91 30.27 1.98 32.07 2.05 33.38 2.08 35.69 2.12 37.49 2.16
80 27.76 2.01 29.56 2.08 31.36 2.16 32.66 2.18 34.97 2.22 36.77 2.27
85 27.06 2.11 28.86 2.18 30.66 2.26 31.96 2.29 34.25 2.33 36.05 2.38
90 26.37 2.21 28.16 2.29 29.95 2.37 31.25 2.40 33.54 2.44 35.33 2.49
95 25.61 2.30 27.40 2.39 29.18 2.47 30.00 2.50 32.75 2.55 34.53 2.60
100 24.99 2.40 26.77 2.49 28.56 2.58 29.61 2.61 32.13 2.66 33.91 2.71
105 24.37 2.50 26.15 2.59 27.93 2.68 29.22 2.72 31.50 2.77 33.29 2.82
110 23.74 2.60 25.53 2.69 27.31 2.79 28.60 2.82 30.88 2.87 32.66 2.93
115 23.12 2.69 24.90 2.79 26.69 2.90 27.98 2.93 30.26 2.98 32.04 3.04
118 22.74 2.75 24.53 2.85 26.31 2.96 27.60 2.99 29.88 3.05 31.67 3.11
122 22.62 2.83 24.40 2.94 26.19 3.04 27.48 3.08 29.76 3.13 31.54 3.20
TC PI TC PI TC PI TC PI TC PI TC PI
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
Combination
Capacity Index
Outdoor Air
Temp.: °FDB
Operation
68 / 57 73 / 61 77 / 64 80 / 67 86 / 72 90 / 75
Indoor Air Temp. °F DB / °F WB
4 UNITS
12 + 12 + 12 + 12
Notes:
1. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25ft
Level difference : 0ft
2. TC : Total Capacity (kBtu/h)
PI : Power Input (kW)
3. indicates reference data. When operating at this temperature,
these values can be different by discontinuous operation.
