n Cooling Capacity
Cooling Capacity
Notes:
1. Capacities are based on the following conditions.
Corresponding refrigerant piping length is accordance with standard length of each outdoor units.
Level difference : 0ft
2. TC : Total Capacity (kBtu/h), SHC: Sensible Heat Capacity(kBtu/h)
3. indicates reference data.
When operating at this temperature, these values can be different by discontinuous operation.
4. Capacities indicated in the above tables are based on unlimited refrigerant flow.
Unit Size
(kBtu/h(kW))
Outdoor
air temp.
°F DB
Indoor Air Temp.: °FDB / °FWB
68 / 57 73 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
9
(2.64)
12
(3.52)
14 8.82 7.55 9.37 7.98 9.92 7.72 10.31 7.89 11.01 7.95 11.56 8.10
20 8.82 7.61 9.36 8.04 9.91 7.78 10.31 7.95 11.01 8.01 11.55 8.17
25 8.81 7.67 9.36 8.10 9.90 7.84 10.30 8.01 11.00 8.08 11.54 8.23
30 8.80 7.73 9.35 8.16 9.90 7.90 10.29 8.07 10.99 8.14 11.54 8.29
35 8.80 7.79 9.34 8.22 9.89 7.96 10.28 8.13 10.98 8.20 11.53 8.36
40 8.79 7.84 9.33 8.29 9.88 8.02 10.27 8.19 10.97 8.26 11.52 8.42
45 8.78 7.90 9.33 8.35 9.87 8.08 10.27 8.25 10.96 8.32 11.51 8.48
50 8.78 7.96 9.32 8.41 9.87 8.14 10.26 8.31 10.96 8.38 11.50 8.54
55 8.77 8.02 9.31 8.47 9.86 8.20 10.25 8.38 10.95 8.45 11.49 8.61
60 8.76 8.08 9.31 8.53 9.85 8.26 10.24 8.44 10.94 8.51 11.48 8.67
65 8.76 8.14 9.30 8.59 9.84 8.32 10.24 8.50 10.93 8.57 11.47 8.73
70 8.75 8.19 9.29 8.66 9.84 8.38 10.23 8.56 10.92 8.63 11.47 8.79
75 8.54 8.06 9.08 8.52 9.62 8.26 10.01 8.44 10.71 8.53 11.25 8.69
80 8.33 7.92 8.87 8.39 9.41 8.14 9.80 8.33 10.49 8.42 11.03 8.59
85 8.12 7.78 8.66 8.25 9.20 8.02 9.59 8.20 10.28 8.30 10.82 8.48
90 7.91 7.63 8.45 8.10 8.99 7.89 9.37 8.08 10.06 8.19 10.60 8.37
95 7.68 7.55 8.22 8.03 8.75 7.83 9.00 7.90 9.83 8.14 10.36 8.34
100 7.50 7.35 8.03 7.83 8.57 7.64 8.88 7.78 9.64 7.97 10.17 8.16
105 7.31 7.15 7.84 7.63 8.38 7.45 8.77 7.66 9.45 7.79 9.99 7.99
110 7.12 6.90 7.66 7.38 8.19 7.22 8.58 7.43 9.26 7.57 9.80 7.77
115 6.94 6.69 7.47 7.17 8.01 7.03 8.39 7.24 9.08 7.39 9.61 7.60
118 6.82 6.65 7.36 7.13 7.89 7.00 8.28 7.21 8.96 7.37 9.50 7.58
122 6.79 6.63 7.32 7.11 7.86 6.98 8.24 7.19 8.93 7.36 9.46 7.57
14 11.76 9.94 12.49 10.50 13.22 10.17 13.75 10.38 14.69 10.47 15.42 10.67
20 11.75 10.02 12.48 10.58 13.21 10.25 13.74 10.46 14.67 10.55 15.40 10.75
25 11.75 10.09 12.48 10.66 13.20 10.33 13.73 10.54 14.66 10.63 15.39 10.83
30 11.74 10.17 12.47 10.75 13.19 10.40 13.72 10.62 14.65 10.71 15.38 10.92
35 11.73 10.25 12.46 10.83 13.18 10.48 13.71 10.70 14.64 10.79 15.37 11.00
40 11.72 10.33 12.45 10.91 13.17 10.56 13.70 10.79 14.63 10.88 15.36 11.08
45 11.71 10.40 12.44 10.99 13.16 10.64 13.69 10.87 14.62 10.96 15.35 11.16
50 11.70 10.48 12.43 11.07 13.15 10.72 13.68 10.95 14.61 11.04 15.33 11.25
55 11.69 10.56 12.42 11.15 13.14 10.80 13.67 11.03 14.60 11.12 15.32 11.33
60 11.68 10.63 12.41 11.23 13.13 10.88 13.66 11.11 14.59 11.20 15.31 11.41
65 11.67 10.71 12.40 11.31 13.12 10.96 13.65 11.19 14.57 11.28 15.30 11.49
70 11.66 10.79 12.39 11.40 13.11 11.03 13.64 11.27 14.56 11.36 15.29 11.58
75 11.38 10.61 12.11 11.22 12.83 10.88 13.35 11.12 14.27 11.22 15.00 11.45
80 11.10 10.43 11.82 11.05 12.55 10.72 13.07 10.96 13.99 11.08 14.71 11.31
85 10.83 10.24 11.54 10.86 12.26 10.55 12.78 10.80 13.70 10.93 14.42 11.17
90 10.55 10.04 11.26 10.67 11.98 10.38 12.50 10.63 13.42 10.78 14.13 11.02
95 10.25 9.94 10.96 10.57 11.67 10.30 12.00 10.40 13.10 10.72 13.81 10.97
100 10.00 9.67 10.71 10.31 11.42 10.06 11.84 10.24 12.85 10.49 13.56 10.75
105 9.75 9.41 10.46 10.04 11.17 9.81 11.69 10.08 12.60 10.26 13.31 10.52
110 9.50 9.09 10.21 9.72 10.92 9.51 11.44 9.78 12.35 9.97 13.07 10.24
115 9.25 8.81 9.96 9.44 10.67 9.26 11.19 9.53 12.10 9.73 12.82 10.00
118 9.10 8.75 9.81 9.39 10.52 9.21 11.04 9.49 11.95 9.70 12.67 9.98
122 9.05 8.73 9.76 9.37 10.48 9.19 10.99 9.47 11.90 9.69 12.62 9.97
