Friedrich MULTI ZONE MR24DY3JMA - 10. Installation

14 _ Ceiling concealed duct - low static pressure
Part 2 Product data_Indoor units
MULTI ZONEMULTI ZONE
10. Installation
• Please read the instruction sheets completely before installing the product.
• When the power cord is damaged, replacement work shall be performed by authorized personnel only.
• Installation work must be performed in accordance with the national wiring standards.
Air outlet vents
Air filters
Control box
Air intake vents
10.1 Accessories
Check the following accessories are included with your unit.
1) Standard accessories
Name
Quantity
Shape
for gas pipe
for liquid pipe
Clamp metal
2 EA
Insulation for
fitting
1 set
Drain hose
1 EA
Clamp
(Tie Wrap)
8 EA
Washer for
hanging bracket
4 EA
Other
• Screws for fixing panels are attached to decoration panel.
• Owner's manual
• Installation manual
