Friedrich MULTI ZONE MR24DY3JMA - 3. Combination table

Multiple piping type _ 3
MULTI ZONEMULTI ZONE
Part 2 Product data_Outdoor units
3. Combination table
Models : MR24DY3JMA
Cooling
n Non ducted type indoor unit
Heating
Cooling
n Ducted type indoor unit
Heating
Note :
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C (80°F) DB / 19.4°C (67°F) WB
- Outdoor Temperature 35°C (95°F) DB / 23.9°C (75°F) WB
Heating: - Indoor Temperature 21.1°C (70°F) DB / 15.6°C (60°F) WB
- Outdoor Temperature 8.3°C (47°F) DB / 6.1°C (43°F) WB
Piping Length - Interconnecting Piping Length 7.6m (25ft)
- Level Difference of Zero
2. Wiring cable size must comply with the applicable local and national codes.
3. The specification may be subject to change without prior notice for purpose
of improvement.
4. Maximum sum of connected indoor units capacity is 33 kBtu/h.
5. At least two indoor units should be connected.
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
COP HSPF
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 9,900 9,900 - - 11,880 3.48 19,800 5.8 22,770 6.67 1,197 1,710 2,394 3.4 9.2
9 12 - - 21 9,900 13,200 - - 13,860 4.06 23,100 6.77 26,565 7.79 1,323 1,890 2,580 3.6 9.7
2 UNIT 12 12 - - 24 12,000 12,000 - - 14,400 4.22 24,000 7.03 27,600 8.09 1,358 1,940 2,580 3.6 9.8
9 18 - - 27 8,000 16,000 - - 14,400 4.22 24,000 7.03 27,600 8.09 1,358 1,940 2,580 3.6 9.8
12 18 - - 30 9,600 14,400 - - 14,400 4.22 24,000 7.03 27,600 8.09 1,358 1,940 2,580 3.6 9.8
9 9 9 - 27 8,000 8,000 8,000 - 14,400 4.22 24,000 7.03 28,800 8.44 1,260 1,800 2,520 3.9 10.6
3 UNIT 9 9 12 - 30 7,200 7,200 9,600 - 14,400 4.22 24,000 7.03 28,800 8.44 1,260 1,800 2,520 3.9 10.6
9 12 12 - 33 6,545 8,727 8,727 - 14,400 4.22 24,000 7.03 28,800 8.44 1,260 1,800 2,520 3.9 10.6
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
EER SEER
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 8,010 8,010 - - 9,612 2.82 16,020 4.70 19,224 5.63 1,054 1,505 2,107 10.6 16.2
9 12 - - 21 7,629 10,171 - - 10,680 3.13 17,800 5.22 21,360 6.26 1,156 1,651 2,312 10.8 16.4
2 UNIT 12 12 - - 24 8,900 8,900 - - 10,680 3.13 17,800 5.22 21,360 6.26 1,156 1,651 2,312 10.8 16.4
9 18 - - 27 5,933 11,867 - - 10,680 3.13 17,800 5.22 21,360 6.26 1,156 1,651 2,312 10.8 16.4
12 18 - - 30 7,120 10,680 - - 10,680 3.13 17,800 5.22 21,360 6.26 1,156 1,651 2,312 10.8 16.4
9 9 9 - 27 5,933 5,933 5,933 - 10,680 3.13 17,800 5.22 22,250 6.52 1,084 1,548 2,167 11.5 17.5
3 UNIT 9 9 12 - 30 5,340 5,340 7,120 - 10,680 3.13 17,800 5.22 22,250 6.52 1,084 1,548 2,167 11.5 17.5
9 12 12 - 33 4,855 6,473 6,473 - 10,680 3.13 17,800 5.22 22,250 6.52 1,084 1,548 2,167 11.5 17.5
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
COP HSPF
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 9,281 9,281 - - 11,138 3.26 18,563 5.44 21,347 6.26 1,275 1,822 2,551 3.0 8.5
9 12 - - 21 9,281 12,375 - - 12,994 3.81 21,656 6.35 24,905 7.3 1,410 2,014 2,580 3.2 9.0
2 UNIT 12 12 - - 24 11,200 11,200 - - 13,440 3.94 22,400 6.57 25,760 7.55 1,447 2,067 2,580 3.2 9.1
9 18 - - 27 7,467 14,933 - - 13,440 3.94 22,400 6.57 25,760 7.55 1,447 2,067 2,580 3.2 9.1
12 18 - - 30 8,960 13,440 - - 13,440 3.94 22,400 6.57 25,760 7.55 1,447 2,067 2,580 3.2 9.1
9 9 9 - 27 7,467 7,467 7,467 - 13,440 3.94 22,400 6.57 26,880 7.88 1,343 1,918 2,685 3.4 9.8
3 UNIT 9 9 12 - 30 6,720 6,720 8,960 - 13,440 3.94 22,400 6.57 26,880 7.88 1,343 1,918 2,685 3.4 9.8
9 12 12 - 33 6,109 8,145 8,145 - 13,440 3.94 22,400 6.57 26,880 7.88 1,343 1,918 2,685 3.4 9.8
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
EER SEER
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 9,000 9,000 - - 10,800 3.17 18,000 5.28 21,600 6.33 1,008 1,440 2,016 12.5 20.1
9 12 - - 21 8,571 11,429 - - 12,000 3.52 20,000 5.86 24,000 7.03 1,106 1,580 2,212 12.7 20.3
2 UNIT 12 12 - - 24 10,000 10,000 - - 12,000 3.52 20,000 5.86 24,000 7.03 1,106 1,580 2,212 12.7 20.3
9 18 - - 27 6,667 13,333 - - 12,000 3.52 20,000 5.86 24,000 7.03 1,106 1,580 2,212 12.7 20.3
12 18 - - 30 8,000 12,000 - - 12,000 3.52 20,000 5.86 24,000 7.03 1,106 1,580 2,212 12.7 20.3
9 9 9 - 27 6,667 6,667 6,667 - 12,000 3.52 20,000 5.86 25,000 7.33 1,037 1,481 2,073 13.5 21.7
3 UNIT 9 9 12 - 30 6,000 6,000 8,000 - 12,000 3.52 20,000 5.86 25,000 7.33 1,037 1,481 2,073 13.5 21.7
9 12 12 - 33 5,455 7,273 7,273 - 12,000 3.52 20,000 5.86 25,000 7.33 1,037 1,481 2,073 13.5 21.7
