Friedrich MULTI ZONE MR24DY3JMA - Page 84

4 _ Multiple piping type
MULTI ZONEMULTI ZONE
Part 2 Product data_Outdoor units
3. Combination table
Note :
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C (80°F) DB / 19.4°C (67°F) WB
- Outdoor Temperature 35°C (95°F) DB / 23.9°C (75°F) WB
Heating: - Indoor Temperature 21.1°C (70°F) DB / 15.6°C (60°F) WB
- Outdoor Temperature 8.3°C (47°F) DB / 6.1°C (43°F) WB
Piping Length - Interconnecting Piping Length 7.6m (25ft)
- Level Difference of Zero
2. Wiring cable size must comply with the applicable local and national codes.
3. The specification may be subject to change without prior notice for purpose
of improvement.
4. Maximum sum of connected indoor units capacity is 33 kBtu/h.
5. At least two indoor units should be connected.
Models : MR24DY3JMA
Cooling
n Mixed type indoor unit
Heating
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
EER SEER
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 8,505 8,505 - - 10,206 2.99 17,010 4.99 20,412 5.98 1,031 1,473 2,062 11.6 18.1
9 12 - - 21 8,100 10,800 - - 11,340 3.32 18,900 5.54 22,680 6.65 1,131 1,616 2,262 11.7 18.4
2 UNIT 12 12 - - 24 9,450 9,450 - - 11,340 3.32 18,900 5.54 22,680 6.65 1,131 1,616 2,262 11.7 18.4
9 18 - - 27 6,300 12,600 - - 11,340 3.32 18,900 5.54 22,680 6.65 1,131 1,616 2,262 11.7 18.4
12 18 - - 30 7,560 11,340 - - 11,340 3.32 18,900 5.54 22,680 6.65 1,131 1,616 2,262 11.7 18.4
9 9 9 - 27 6,300 6,300 6,300 - 11,340 3.32 18,900 5.54 23,625 6.92 1,060 1,515 2,120 12.5 19.6
3 UNIT 9 9 12 - 30 5,670 5,670 7,560 - 11,340 3.32 18,900 5.54 23,625 6.92 1,060 1,515 2,120 12.5 19.6
9 12 12 - 33 5,155 6,873 6,873 - 11,340 3.32 18,900 5.54 23,625 6.92 1,060 1,515 2,120 12.5 19.6
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
COP HSPF
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 9,591 9,591 - - 11,509 3.37 19,181 5.62 22,058 6.46 1,236 1,766 2,472 3.2 8.9
9 12 - - 21 9,591 12,788 - - 13,427 3.94 22,378 6.56 25,735 7.54 1,366 1,952 2,580 3.4 9.4
2 UNIT 12 12 - - 24 11,625 11,625 - - 13,950 4.09 23,250 6.81 26,738 7.84 1,403 2,004 2,580 3.4 9.5
9 18 - - 27 7,750 15,500 - - 13,950 4.09 23,250 6.81 26,738 7.84 1,403 2,004 2,580 3.4 9.5
12 18 - - 30 9,300 13,950 - - 13,950 4.09 23,250 6.81 26,738 7.84 1,403 2,004 2,580 3.4 9.5
9 9 9 - 27 7,750 7,750 7,750 - 13,950 4.09 23,250 6.81 27,900 8.18 1,301 1,859 2,603 3.7 10.2
3 UNIT 9 9 12 - 30 6,975 6,975 9,300 - 13,950 4.09 23,250 6.81 27,900 8.18 1,301 1,859 2,603 3.7 10.2
9 12 12 - 33 6,341 8,455 8,455 - 13,950 4.09 23,250 6.81 27,900 8.18 1,301 1,859 2,603 3.7 10.2
