74 _ Multiple piping type
MULTI ZONEMULTI ZONE
Part 2 Product data_Outdoor units
7. Capacity tables
Models : MR36TQY3JMA
Heating capacity
n Mixed type indoor unit
Operation
Combination
Capacity Index
(kBtu/h)
Outdoor Air
Temp.
Indoor Air Temp.: °FDB
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
°F DB °F WB kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-4 -4.4 12.40 1.97 11.64 2.05 11.48 2.07 11.32 2.08 11.19 2.10 10.72 2.17
0 -0.4 14.28 2.00 13.52 2.08 13.26 2.11 13.06 2.13 12.90 2.15 12.36 2.22
5 4.5 16.59 2.05 15.83 2.12 15.44 2.16 15.19 2.19 14.99 2.21 14.38 2.28
10 9 18.70 2.08 17.95 2.16 17.44 2.21 17.14 2.24 16.90 2.26 16.24 2.34
17 15 21.52 2.14 20.77 2.20 20.11 2.27 19.75 2.31 19.46 2.34 18.71 2.41
20 19 23.40 2.17 22.65 2.24 21.89 2.31 21.49 2.36 21.16 2.39 20.36 2.46
25 23 26.54 2.23 25.75 2.30 24.86 2.39 24.38 2.43 24.01 2.47 23.11 2.54
30 28 29.70 2.31 28.78 2.38 27.79 2.46 27.28 2.51 26.87 2.55 25.89 2.62
35 32 32.86 2.38 31.81 2.47 30.73 2.53 30.18 2.59 29.74 2.64 28.66 2.70
40 36 34.53 2.45 33.56 2.54 32.49 2.61 31.93 2.66 31.48 2.71 30.34 2.78
45 41 36.63 2.54 35.75 2.62 34.70 2.70 34.12 2.75 33.66 2.79 32.44 2.87
47 43 37.47 2.57 36.63 2.66 35.58 2.74 35.00 2.79 34.53 2.83 33.28 2.91
50 46 37.58 2.56 36.82 2.63 35.91 2.71 35.39 2.75 34.97 2.78 33.79 2.86
55 51 37.76 2.53 37.13 2.59 36.45 2.65 36.03 2.68 35.69 2.71 34.64 2.77
60 56 37.94 2.50 37.45 2.55 36.99 2.60 36.67 2.62 36.42 2.63 35.49 2.67
63 59 38.05 2.49 37.64 2.53 37.31 2.56 37.06 2.58 36.85 2.59 36.00 2.62
68 64 38.16 2.47 37.83 2.50 37.64 2.53 37.45 2.54 37.29 2.54 36.51 2.56
-4 -4.4 12.40 1.97 11.64 2.05 11.48 2.07 11.32 2.08 11.19 2.10 10.72 2.17
0 -0.4 14.28 2.00 13.52 2.08 13.26 2.11 13.06 2.13 12.90 2.15 12.36 2.22
5 4.5 16.59 2.05 15.83 2.12 15.44 2.16 15.19 2.19 14.99 2.21 14.38 2.28
10 9 18.70 2.08 17.95 2.16 17.44 2.21 17.14 2.24 16.90 2.26 16.24 2.34
17 15 21.52 2.14 20.77 2.20 20.11 2.27 19.75 2.31 19.46 2.34 18.71 2.41
20 19 23.40 2.17 22.65 2.24 21.89 2.31 21.49 2.36 21.16 2.39 20.36 2.46
25 23 26.54 2.23 25.75 2.30 24.86 2.39 24.38 2.43 24.01 2.47 23.11 2.54
30 28 29.70 2.31 28.78 2.38 27.79 2.46 27.28 2.51 26.87 2.55 25.89 2.62
35 32 32.86 2.38 31.81 2.47 30.73 2.53 30.18 2.59 29.74 2.64 28.66 2.70
40 36 34.53 2.45 33.56 2.54 32.49 2.61 31.93 2.66 31.48 2.71 30.34 2.78
45 41 36.63 2.54 35.75 2.62 34.70 2.70 34.12 2.75 33.66 2.79 32.44 2.87
47 43 37.47 2.57 36.63 2.66 35.58 2.74 35.00 2.79 34.53 2.83 33.28 2.91
50 46 37.58 2.56 36.82 2.63 35.91 2.71 35.39 2.75 34.97 2.78 33.79 2.86
55 51 37.76 2.53 37.13 2.59 36.45 2.65 36.03 2.68 35.69 2.71 34.64 2.77
60 56 37.94 2.50 37.45 2.55 36.99 2.60 36.67 2.62 36.42 2.63 35.49 2.67
63 59 38.05 2.49 37.64 2.53 37.31 2.56 37.06 2.58 36.85 2.59 36.00 2.62
68 64 38.16 2.47 37.83 2.50 37.64 2.53 37.45 2.54 37.29 2.54 36.51 2.56
4 UNIT
9 + 9 + 12 + 18
12 + 12 + 12 + 12
Notes:
1. Capacities are based on the following conditions.
Corresponding refrigerant piping length : 25ft
Level difference : 0ft
2. TC : Total Capacity (kBtu/h)
PI : Power Input (kW)
